Поз.
Артикул
Описание
5
BATTERY MAINTENANCE-FREE 12V/200 AH, SA 67062/01
5
BATTERY , Replaced By: A0045414401
5
STARTER BATTERY LOW-MAINTENANCE 12V/200AH
5
BATTERY FILLED AND CHARGED 12V/200AH
9
CABLE HARNESS FROM BATTERY I TO BATTERY II
11
ELECTRICAL LINE GROUND LEAD FROM BATTERY TO BODY
13
CABLE HARNESS
13
ELECTRICAL LINE
13
CABLE HARNESS BATTERY CUT-OUT
13
BATTERY CABLE UP TO GROUND (ENGINE COMPARTMENT)
13
ELECTRICAL CABLE FROM FUSE BOX TO STARTING MOTORREUR
13
ELECTRICAL LINE ELECTRIC CABLE TO BATTERY MASTER SWITCH AND TO BATTERY CUT-OFF,RESP.
15
ELECTRICAL LINE FROM BATTERY POS. POLE TO MECHANICAL CUT-OUT
20
NUT BATTERY CABLE
20
HEXAGON NUT. NUT ELECTRIC CABLE TO ALTERNATOR
23
LOCK WASHER FUSE
23
LOCK WASHER
27
ECCENTRIC SCREW ROLLER BLIND TO BODY M6X16 T30
27
HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X60
27
SCREWM 10X20
27
SCREW VALVE TO BRACKET M 8X60
44
CLAMPING RAIL ,086410
47
SCREW BATTERY MOUNTING
50
TUBE BATTERY MOUNTING
51
SWITCH BATTERY CUT-OFF
52
CAP BATTERY MASTER SWITCH
53
KEY BATTERY CUT-OFF " KISSLING "
54
SCREW. HEXAGON HEAD BOLT SENDER UNIT TO BRACKET M5X25,V 214287
54
SCREW STEERING COLUMN MOUNTED SWITCH PLUGCONNECTION
54
SCREWM6X25
54
SCREW LINE MOUNTING M 6X45
54
SCREW. HEXAGON HEAD BOLT RELAY TO BRACKET M5X16
55
NUT BALL PIVOT TO LEVER
55
HEXAGON NUT. NUT ELECTRIC CABLE TO ALTERNATOR
55
NUT
55
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
55
HEXAGON NUTM14X1.5
56
BRACKET BATTERY CUT-OFF
62
VENT , Replaced By: A0005410847
63
BOOT. PROTECTIVE CAP CONNECTION TO BATTERY CUT-OFF
65
SEAL RING BATTERY COVER
68
HOSE BATTERY VENTING 11 X 2 MM, ORDER BY THE METER
