Поз.
Артикул
Описание
5
8
GREASE NIPPLE
10
STEERG. WORM SECTOR SHAFT
11
DRIVE FLANGE
12
12
STEERING SHAFT , USED WITH SHORT MERCEDES-BENZ CAB
13
UNIVERSAL JOINT ,5 463985
14
PITMAN ARM
15
TIE ROD
16
DRAG LINK END R.H. THREAD
17
18
CLAMP
19
PLATE
20
NUT DRAG LINK END M 24X1.5
23
HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X60
23
HEXAGON HEAD BOLT. SCREW CONSOLE TO CAB, FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB5 251746
26
HEXAGON HEAD BOLT BEARING BRACKET TO FRAME M18X1.5X120
26
HEXAGON HEAD BOLT STEERING BRACKET TO FRAME M18X1.5X120,V 207570
29
NUT SUPPORT TO FRAME
29
NUT STEERING SUPPORT TO FRAME,D 523394
29
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
32
NUT TRAILER COUPLING TO FRONT CROSS MEMBER M18X1.5
32
NUT RETARDER HOUSING TO TRANSMISSION CASE
35
SCREWM20X1.5X40
38
SCREW STEERING SHAFT TO STEERING M 8X42
41
NUT STRAP TO BRACKET
