Поз.
Артикул
Описание
12
OIL PAN
12
OIL PAN
12
OIL PAN
12
OIL PAN
12
OIL PAN
18
SCREW PLUG
24
THREADED INSERT
24
THREADED INSERT REPAIR SIZE, TO BE ADAPTED DURING ASSEMBLY
32
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
38
SCREW PLUG
44
STUD BOLT
50
GASKET COVER TO OIL PAN
56
COVER OIL PAN
64
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
70
NUT
70
NUT , Replaced By: N304032008006
76
OIL DIPSTICK
76
OIL DIPSTICK
76
OIL DIPSTICK
82
GUIDE TUBE
82
GUIDE TUBE
88
GUIDE TUBE
96
SPACER TUBE GUIDE TUBE TO CYLINDER CRANKCASE
104
HEXAGON HEAD BOLT BRACKET TO TRANSMISSION
110
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
116
OIL PUMP
122
OIL PUMP , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3271800601
128
SUCTION PIPE
128
SUCTION PIPE
134
SCREW BRACKET TO EXHAUST PIPE BRACKET
134
SCREW , Replaced By: N304017008024
140
WASHER , 034 UP TO CHASSIS A 004589
152
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
152
SCREW , Replaced By: N304017008016
158
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
164
NUT
164
NUT , Replaced By: N304032008006
170
SCREW , Replaced By: N304014008021
170
SCREW BRACKET TO ALTERNATOR
170
HEXAGON HEAD BOLT. SCREW EXHAUST PIPE TO MUFFLER
177
CLAMP SUCTION PIPE TO BRACKET
183
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
189
SCREW PIPE CLAMP
189
SCREW , Replaced By: N304017008021
195
EXPANSION PLUG
999
OIL DIPSTICK
999
OIL DIPSTICK , Replaced By: A3600102072
999
OIL PUMP , UNTIL PRODUCTION STOP OM 327, Replaced By: A3271801401, +001A3601800752
999
BRACKET
999
SUCTION PIPE
999
GUIDE TUBE , Replaced By: A3600100066
999
OIL DIPSTICK , Replaced By: A3600101372
999
OIL DIPSTICK , Replaced By: A3600102172
999
OIL PUMP , Replaced By: A3271801601
999
SUCTION PIPE
999
OIL PUMP , Replaced By: A3271801401, +001A3601800852
999
OIL PUMP , Replaced By: A3271801401, +001A3601800252, +001A3601860080, +002N000931008086
999
SHIM SUCTION PIPE TO OIL PAN
999
SCREW PLUG , Replaced By: A4039970230
999
GUIDE TUBE , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 036669, Replaced By: A3520102566
999
GUIDE TUBE , Replaced By: A3520184216
999
OIL DIPSTICK , Replaced By: A3600101272
999
OIL PAN , Replaced By: A3600100313, +001N007603018101, +001N007604018101
999
OIL PAN , Replaced By: A3600102713, +001A3600100140, +001A4030103166, +001A3600102872
999
OIL PAN , Replaced By: A3270100313
999
OIL DIPSTICK
999
SCREW PLUG
999
SCREW PLUG , Replaced By: N007604018101
