Mercedes A0115451628 - Штифт

G 320 CDI 463.303 FROM CHASSIS 144226

54 ELECTRICAL EQUIPMENT AND INSTRUMENTS - 420 MAIN CABLE HARNESS IL. 3

Поз.
Артикул
Описание
30
A0125458228
PLUG HOUSINGADS-ASD
40
A0115451628
PLUG PIN
50
A0295455528
PIN BUSHING HOUSING WARNING DEVICE
60
A0085455526
CONTACT BUSHINGR 27, 0.75 MM2
60
A0005404605
REP.SET CONTACT0.75 MM2 MQS, CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED. SEE WIS FOR REPAIR INSTRUCTIONS.SOLDER CONNECTOR SLEEVES:TOTAL WIRE CROSS-SECTION: A 001 546 99 41GREEN0.7 -2.4 MM2 A 002 546 00 41RED2.0 -4.0 MM2 A 002 546 01 41BLUE 3.5 -8.0 MM2 A 002 546 11 41YELLOW 7.5 - 12.0 MM2 BUTT JOINT: A 002 546 13 41 0.5 MM2 A 002 546 14 41 0.8 MM2 A 002 546 15 41 1.3 MM2 A 002 546 16 41 2.0 MM2
70
A4145450026
PLUG HOUSING ILLUMINATED DOOR SILL MOLDING CONTROL UNIT 8-PIN AMP SERIE 040,N99/9,N99/10
80
A0165457826
PIN BUSHING0.35-0.5 MM2 AMP SERIE 040
210
A0305455928
PLUG INFRARED REMOTE CONTROL RECEIVER, FRONT DOOR, FROM MODEL YEAR 1999
220
A0325453928
PLUG PINX 209, 0.75 MM2
