Поз.
Артикул
Описание
48
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
144
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
144
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
164
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
176
BATTERY SUPPORT , TO BE ADAPTED DURING ASSEMBLY
176
BATTERY SUPPORT , Replaced By: A6165400316
176
BATTERY SUPPORT , Replaced By: A6205401916
176
BATTERY SUPPORT , Replaced By: A6205400016
184
SCREW PIPE CLAMP
184
SCREW , Replaced By: N304017008021
184
SCREW PIPE CLAMP
184
SCREW PIPE CLAMP
184
SCREW , Replaced By: N304017008021
190
SCREW PIPE CLAMP
190
SCREW PIPE CLAMP
190
SCREW , Replaced By: N304017008021
191
NUT STRAP TO BRACKET
191
NUT , Replaced By: N910113010000
192
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
192
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
192
NUT , Replaced By: N913004008001
196
RIVET FRAME TRUSS TO SIDE MEMBER
200
PRESSURE REGULATORKNORR
200
PRESSURE REGULATORWABCO
200
PRESSURE REGULATORWABCO, Replaced By: A0034313806
200
PRESSURE REGULATORBOSCH,241, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
200
PRESSURE REGULATORBOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0034313606
200
PRESSURE REGULATORKNORR
200
PRESSURE REGULATORWABCO
200
PRESSURE REGULATORBOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
208
REPAIR KIT SEAL RING BOSCH,209
208
REPAIR KIT DIAPHRAGM PART BOSCH,209
208
REPAIR KIT PRESSURE REGULATOR KNORR
208
REPAIR KIT PRESSURE REGULATOR KNORR
208
REPAIR KIT PRESSURE REGULATOR WABCO
208
REPAIR KIT PRESSURE REGULATOR BOSCH,241
208
REPAIR KIT SEAL RING BOSCH,209
208
REPAIR KIT DIAPHRAGM PART BOSCH,209
224
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
224
SCREW PLUG , Replaced By: N000908012009
232
THRUST RING CHECK VALVE TO AIR RESERVOIR
232
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
240
O-RING CHECK VALVE TO AIR RESERVOIR
248
HOLLOW SCREW HEATING CONNECTION
248
HOLLOW SCREW HEATING CONNECTION
248
HOLLOW SCREW HEATING CONNECTION
256
SEAL RING LINE CONNECTION
264
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
264
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
265
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
265
CLAMP , Replaced By: N000000000667
266
GROMMET LINE PASSAGE AT SIDE MEMBER 32/27 MM
268
BRACKET , Replaced By: A6454311240
268
BRACKET PRESSURE REGULATOR
268
BRACKET PRESSURE REGULATOR
268
BRACKET PRESSURE REGULATOR
268
BRACKET PRESSURE REGULATOR
268
BRACKET PRESSURE REGULATOR
269
SCREW , Replaced By: N304017010002
269
SCREW BRACKET TO SIDE MEMBER
269
SCREW BRACKET TO SIDE MEMBER
270
NUT , Replaced By: N910113010000
270
NUT STRAP TO BRACKET
272
AIR DEHYDRATOR
272
AIR DEHYDRATOR
280
STRAINER FILTER ELEMENT
284
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
288
SEAL RING
294
NUT , Replaced By: N910113010000
294
NUT STRAP TO BRACKET
296
STRAINER
304
SEAL RING
312
VALVE SOLENOID SWITCH
314
ANGLETO 000 431 46 15
320
REPAIR KIT CHECK VALVE WABCO
328
REPAIR KITWABCO
440
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
440
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
440
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
440
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
442
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
442
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
448
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
448
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
452
SCREW , Replaced By: N304017008016
452
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
452
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
454
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
454
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
458
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
458
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
458
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
458
FITTING AIR RESERVOIR,CONNECTION: "11"
458
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
999
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
FITTING , Replaced By: A0009907771
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
999
SCREW PLUG , Replaced By: N000908022011
999
BATTERY SUPPORT
999
BRACKET , Replaced By: A6554318840
999
BRACKET , Replaced By: A6484320340
999
SUPPORT SERVICE BRAKE AIR RESERVOIR
999
BASE AIR RESERVOIR TO RIGHT SIDE MEMBER, INSIDE
999
STRAP SPRING-LOADED BRAKE AIR RESERVOIR
999
BRACKET AIR DEHYDRATOR,5 433280
999
STRAP AIR RESERVOIR III,5 088362
999
STRAP AIR RESERVOIR TO BRACKET
999
BRACKET AIR DEHYDRATOR,5 339169
999
STRAP AIR RESERVOIR
999
STRAP AIR RESERVOIR,FOUR-CIRCUIT PROTECTIVE VALVE
999
STRAP FRONT AIR RESERVOIR,RIGHT
999
BRACKET AIR RESERVOIR TO FRAME
999
ELBOW FITTING CHECK VALVE TO RELAY VALVE
999
VALVE (OVERFLOW VALVE) GRAU
999
VALVE (OVERFLOW VALVE) WABCO
999
T-FITTING PRESSURE RELIEF VALVE,CONNECTION: "10"
999
VALVE (PRESSURE LIMIT VALVE)
999
ELBOW FITTING , Replaced By: A0049906471
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
RESERVOIR , Replaced By: A0034321401
999
RESERVOIR , Replaced By: A0034322301
999
AIR DEHYDRATOR"WABCO",5 502947
999
REPAIR KIT PRESSURE LIMIT VALVE
999
ELBOW FITTING COMBINATION CYLINDER,CONNECTION: "12"
999
AIR CLEANERBOSCH
999
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
