Поз.
Артикул
Описание
80
BOOT RADIATOR
80
BOOT RADIATOR
80
BOOT FAN SHROUD
193
AIR BAFFLE ON ENGINE END
193
AIR BAFFLE , Replaced By: A4422000195
197
BRACKET COMPRESSED AIR LINE MOUNTING
201
BRACKET AIR BAFFLE TO CYLINDER CRANKCASE
205
BRACKET AIR BAFFLE TO CYLINDER CRANKCASE
205
BRACKET , Replaced By: A4422053940
205
BRACKET , Replaced By: A4422051240
209
FAN SHROUD RADIATOR
209
FAN SHROUD RADIATOR
209
FAN SHROUD RADIATOR
221
CLIP-TYPE NUT FAN SHROUD TO RADIATOR
227
BRACKET BOOT
230
WASHER COMPRESSED AIR LINE TO BRACKET
230
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
230
WASHER , Replaced By: N000125006421
232
SCREW LICENSE PLATE TO BRACKET
232
SCREW , Replaced By: N304017006020
235
SPRING WASHER LICENSE PLATE TO BRACKET
245
SUPPORT RADIATOR,LEFT
250
RUBBER MOUNTING RADIATOR
254
SCREW HOLLOW RUBBER SPRING TO CAB,5 956657
254
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
254
SCREW , Replaced By: N304017010028
276
SCREW CONSOLE TO SIDE MEMBER
276
SCREW CONSOLE TO SIDE MEMBER
280
NUT SUPPORT TO SIDE MEMBER
280
NUT SUPPORT TO SIDE MEMBER
999
RECEPTACLE SILICONE GREASE
999
BRACKET OIL LINE MOUNTING
999
HOSE FROM ENGINE CONNECTION FLANGE TO HEATING PIPE AT RADIATOR,5 534803
999
HOSE , Replaced By: A3635060235
999
LOCKING CAP INTERMEDIATE PIPE TO PARTICLE FILTER
999
HOSE FROM FLANGE TO HEATING PIPE
999
HOSE CONNECTION OF COOLING WATER LINES
999
BRACKET PIPE ELBOW
999
LINE FEED
999
BRACKET FEED LINE TO ENGINE
999
COOLING WATER LINE FEED
999
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
999
SPRING WASHER STEERING COLUMN BRACKET TO CAB
999
SCREW , Replaced By: N304017006016
999
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
999
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
999
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
999
SCREW PLUGROCKINGER,TYP 59 U150
999
WASHER , Replaced By: N009021006208
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
SCREW PUMP TO BRACKET
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004008001
999
CLAMP , Replaced By: N000000000667
