Поз.
Артикул
Описание
12
CONSOLE CAB SUSPENSION,REAR RIGHT
24
MOUNTING CAB, RIGHT
24
MOUNTING CAB,LEFT
60
BRACKET CONSOLE,RIGHT
66
HEXAGON HEAD BOLT , Replaced By: A0029902704
66
SCREW , Replaced By: N308676012013
72
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
72
NUT , Replaced By: N910113012003
78
SCREW CONSOLE TO SIDE MEMBER
84
WASHER
90
LOCK WASHER FITTING TO BRACKET
96
RAIL CAB SUSPENSION,REAR
96
RAIL , Replaced By: A3878901222
108
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
114
SCREW PIPE ELBOW TO BRACKET M 10X50
114
SCREW , Replaced By: N304017010053
114
SCREW , Replaced By: N304017010030
120
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
132
SCREW VIBRATION ABSORBER TO CONNECTING RAIL M 18X65
138
NUT TORSION BAR TO BEARING BRACKET,5 904661
144
SPACER TUBE SHOCK ABSORBER TO RAIL
144
SPACER TUBE MOUNTING TO CONSOLE
144
SPACER TUBE SHOCK ABSORBER TO RAIL
150
SCREW VIBRATION ABSORBER TO CONSOLE
150
SCREW SUPPORTING ARM TO CYLINDER CRANKCASE M 18X60
150
SCREW , Replaced By: N308676018010
150
SCREW VIBRATION ABSORBER TO CONSOLE
162
NUT TORSION BAR TO BEARING BRACKET,5 904661
174
SCREW PLATE TO CENTRAL BEARING
180
NUT TORSION BAR TO BEARING BRACKET,5 904661
999
RUBBER BUFFER SUPPORT TO BRACKET
999
RUBBER BUFFER SUPPORT TO STAY
999
BRACKET AIR CLEANER
999
SCREW BUFFER AND MOUNTING TO RAIL M 8X18
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW , Replaced By: N308676012012
999
SCREW BRACKET TO CAB CONSOLE,K 035197
999
WASHER , Replaced By: N009021010209
999
WASHER BRACKET TO COVERING
999
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
999
NUT SUPPORT TO SIDE MEMBER
