Поз.
Артикул
Описание
30
PITMAN ARM FRONT
33
NUT PITMAN ARM TO STEERING BOX ASSEMBLY,5 386585
36
DRAG LINK FROM PITMAN ARM TO STEERING SUPPORT I
36
DRAG LINK FROM PITMAN ARM TO STEERING SUPPORT I EHRENREICH
36
DRAG LINK , Replaced By: A3914602005
36
DRAG LINK FROM PITMAN ARM TO STEERING SUPPORT I LEMFOERDER
36
DRAG LINK , Replaced By: A3914601905
42
BOOT DRAG LINK
45
DRAG LINK END R.H. THREAD EHRENREICH
45
DRAG LINK END , Replaced By: A0014607748
45
DRAG LINK END , Replaced By: A0014602248
45
DRAG LINK END , Replaced By: A0014600848
48
BOOT DRAG LINK
51
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
54
HEXAGON HEAD BOLT. SCREW CLAMP TO DRAG LINK
54
SCREW , Replaced By: N308676012017
57
NUT SUPPORT TO SIDE MEMBER
60
DRAG LINK FROM STEERING SUPPORT I TO STEERING SUPPORT II EHRENREICH
60
DRAG LINK FROM STEERING SUPPORT I TO STEERING SUPPORT II LEMFOERDER
60
DRAG LINK , Replaced By: A6194604505
63
BOOT DRAG LINK
114
STEERING SUPPORT
117
STEERING SUPPORTI
120
STEERING INTERMEDIATE ARMI
123
SEAL RING INSIDE TO 622 463 01 10
126
SEAL RING INSIDE AND OUTSIDE TO 622 463 01 10
129
THRUST WASHER , Replaced By: A6574630162
132
NEEDLE BEARING INSIDE AND OUTSIDE
135
SPACER TUBE INSIDE
135
SPACER TUBE STEERING INTERMEDIATE ARM BEARING TO 622 461 00 40
138
SEAL RING OUTSIDE TO 622 463 01 10
138
SEAL RING , Replaced By: A0169973648
141
THRUST WASHER , Replaced By: A6574630062
144
GREASE NIPPLE
144
GREASE NIPPLE , Replaced By: N071412008102
147
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
147
NUT , Replaced By: N910113018004
150
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X50
150
SCREW , Replaced By: N308676016007
154
NUT CONSOLE TO SUPPORT
154
NUT , Replaced By: N910113016001
