Поз.
Артикул
Описание
8
SHIFTING ROD (TELESCOPIC SHIFTING ROD)
16
SHIFTING ROD (TELESCOPIC SHIFTING ROD)
16
SHIFTING ROD (TELESCOPIC SHIFTING ROD)
24
ROD END HYDRAULIC RELEASE
32
SEAL RING HYDRAULIC RELEASE
40
PAWL SHIFTING ROD,5 443048
48
BUSHING PAWL TO ROD END,5 443048
48
BUSHING PAWL TO ROD END,5 443048
56
SPACER TUBE SHIFTING ROD TO SHIFT LEVER
64
ROUND CORD RING. SEAL RING ROD END
72
SPRING ROD END
80
SPRING ROD END
88
SCREW SHIFTING ROD TO SHIFT LEVER
88
SCREW , Replaced By: N000933010192
96
NUT , Replaced By: N910113010000
96
NUT STRAP TO BRACKET
104
SHIFTING TUBE (TELESCOPIC TUBE)
104
SHIFTING TUBE (TELESCOPIC TUBE)
112
SHIFTING CYLINDER HYDRAULIC RELEASE TECHNOMATIK
112
SHIFTING CYLINDER HYDRAULIC RELEASE WABCO
120
SEAL RING PISTON RINGS WABCO
128
SEAL RING SCREW FITTING WABCO
136
SEAL RING OUTSIDE WABCO
144
SPRING WASHER SHIFTING CYLINDER TO YOKE
152
PIN SHIFTING CYLINDER TO YOKE 8X45 MM
160
PIN SHIFTING CYLINDER TO PAWL 8X20 MM
168
COTTER PIN LEVER TO ROD
168
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
176
WASHER BETWEEN THE SHIFTING RODS
184
SHIFTING ROD REAR
192
SHIFTING ROD REAR
200
SCREW FRONT SHIFTING ROD TO REAR SHIFTING ROD
208
NUT STRAP TO BRACKET
208
NUT , Replaced By: N910113010000
216
CLAMPING PIECE SHIFTING ROD TO TRANSMISSION
224
CONNECTOR , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6172680028
232
SCREW CONNECTOR TO REAR SHIFTING ROD
240
SCREW CONNECTOR TO REAR SHIFTING ROD
240
SCREW , Replaced By: N304017010047
248
JOINT SHIFTING ROD TO TRANSMISSION
248
JOINT SHIFTING ROD TO TRANSMISSION
256
SCREW SHIFTING ROD TO TRANSMISSION
264
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
272
NUT , Replaced By: N304032008006
272
NUT
280
SPACER TUBE SHIFTING ROD TO SHIFT LEVER
288
ROUND CORD RING. SEAL RING ROD END
296
SCREW SHIFTING ROD TO SHIFT LEVER
296
SCREW , Replaced By: N000933010192
304
SPRING WASHER SHIFTING ROD TO SHIFT LEVER
312
NUT , Replaced By: N910113010000
312
NUT STRAP TO BRACKET
999
SHIFTING ROD , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6522606633
