Поз.
Артикул
Описание
5
FENDER REAR AXLE
5
FENDER REAR AXLE,5 952572
5
FENDER REAR AXLE,5 952573
10
BRACKET FENDER TO BRACKET
10
BRACKET FENDER TO BRACKET, Replaced By: A6205204341
15
RIVET
20
SCREW
25
CLAMPING PIECE
30
NUT
35
SCREW SUPPORTING RAIL TO SUPPORT,5 429712
40
NUT PUMP TO BRACKET
40
NUT , Replaced By: N913004006001
45
REINFORCEMENT FENDER FIXTURE 536 MM
45
REINFORCEMENT FENDER FIXTURE 505 MM
45
REINFORCEMENT FENDER FIXTURE 500 MM
45
REINFORCEMENT FENDER FIXTURE 525 MM
50
STAY
55
BRACKET
60
SCREW
65
FITTED WASHER
65
WASHER , Replaced By: N000988008024
70
NUT , Replaced By: N913004006001
70
NUT PUMP TO BRACKET
80
SHEET METAL SCREW
85
WASHER , Replaced By: N000988008024
85
FITTED WASHER
90
SCREW BRACKET TO REAR FENDER
90
SCREW BRACKET TO FENDER,5 952572
95
SCREW CLAMP MOUNTING M 6X16
95
SCREW , Replaced By: N000000001146
100
WASHER , Replaced By: N009021006208
100
WASHER COMPRESSED AIR LINE TO BRACKET
105
NUT PUMP TO BRACKET
105
NUT , Replaced By: N913004006001
110
COVERING
115
RIVET BINDING RAIL TO COVERING
120
RIVET BRACKET TO BINDING RAIL
125
WASHER COMPRESSED AIR LINE TO BRACKET
125
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
130
BRACKET COVERING TO FRONT FENDER
165
PIN COVERING AND PIN TO FENDER HALF SHELL
170
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
170
SCREW , Replaced By: N000000001149
170
SCREW , Replaced By: A0029903712
175
NUT , Replaced By: N913004006001
175
NUT PUMP TO BRACKET
270
BEARING BRACKET FENDER
280
SCREW PIPE ELBOW TO BRACKET M 10X50
280
SCREW BRACKET TO SIDE MEMBER
280
SCREW EXHAUST PIPE TO BRACKET
280
SCREW REAR EXHAUST PIPE TO MUFFLER
280
SCREW , Replaced By: N304017010030
280
SCREW , Replaced By: N304017010002
280
SCREW , Replaced By: N304017010053
280
SCREW HOLLOW RUBBER SPRING TO CAB,5 956657
285
NUT STRAP TO BRACKET
285
NUT , Replaced By: N910113010000
315
BRACKET , Replaced By: A6525222040
315
BRACKET , Replaced By: A6525222040
315
BRACKET FRONT AXLE II,RIGHT
335
EXPANSION PLUG BRACKET
340
SCREW UNDERRUN PROTECTION AND BRACKET TO FRAME
340
SCREW , Replaced By: N304017010055
340
SCREW , Replaced By: N304017010050
340
SCREW , Replaced By: N304017010050
345
NUT , Replaced By: N910113010000
345
NUT STRAP TO BRACKET
999
BINDING RAIL COVERING
999
BRACKET COVERING
999
BRACKET FENDER TO BRACKET
999
CLAMPING PIECE , Replaced By: A6555220120
999
CLAMPING PIECE BRACKET TO BEARING BRACKET,K 274033
