Поз.
Артикул
Описание
7
PLASTIC PIPE RISING PIPE 4X6 MM
7
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
14
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
21
COUPLING COMPRESSED-AIR-LINE PLUG-CONNECTION
28
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
28
CONNECTOR , Replaced By: A0029905378
35
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
42
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
49
CONNECTOR
56
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
84
HOSE , Replaced By: A0009872827
84
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
91
FITTING (PARTS KIT),LINE RUPTURE
140
BOOT SHIFT LEVER
147
VALVE SHIFT LEVER HERION
147
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 528951, Replaced By: A0012606357
147
VALVE GEARSHIFT LEVER LOWER PART WABCO
154
CLAMPING SLEEVE (SHIFT LEVER VALVE)
161
HANDLE (SHIFT LEVER HANDLE)
168
WASHER RADIATOR TO RUBBER MOUNTING
168
WASHER , Replaced By: N000125010532
175
NUT , Replaced By: N308673010000
175
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
259
BRACKET LINE MOUNTING
266
SCREW COVER PLATE TO COVER PLATE M 6 X 12
266
SCREW , Replaced By: N304017006018
280
LOOM TIE LINE MOUNTING 280 MM
999
SEAL RING
999
SEAL RING , Replaced By: A0229973948
999
SEAL RING CONNECTOR 11.8X2 MM
999
HOSE FUEL LINE, ORDER BY THE METER
999
GUMMED LABEL NINE-SPEED,ASHTRAY,5 032516
999
COVER SHIFT LEVER KNOB LESS GEARSHIFT DIAGRAM
999
CONNECTOR DISTRIBUTOR TO CAB
999
CONNECTOR DISTRIBUTOR OUTPUT, COMPRESSED AIR LINE PLUG CONNECTION
999
CONNECTOR
999
SCREW CONNECTOR
999
SCREW EXHAUST BRAKE SEPARATION POINT
