Поз.
Артикул
Описание
5
RADIATOR WITH SCREW FITTING
5
RADIATOR , FROM IDENT NO. 5 623090, SEE STANDARD MICROFICHE, Replaced By: A6525016601, +001A6552602262, +001A6552602985, +001A6552603085, +001A6559974182, +001A6559974682
5
RADIATOR , FROM IDENT NO. 5 623090, SEE STANDARD MICROFICHE, Replaced By: A6525016601, +001A6552602262, +001A6552602985, +001A6552603085, +001A6559974182, +001A6559974682
5
RADIATOR , Replaced By: A6525014201
8
SCREW WATER DRAIN
11
SEAL RINGTO 000 553 03 05,000 553 18 05,
12
SCREW BRACKET TO BRACKET
14
LOCK
32
RUBBER MOUNTING RADIATOR
35
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
35
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
35
SCREW , Replaced By: N304017010028
38
WASHER RADIATOR TO RUBBER MOUNTING
38
WASHER RADIATOR TO RUBBER MOUNTING
38
WASHER , Replaced By: N000125010532
41
FAN SHROUD RADIATOR
47
DETENT FAN SHROUD TO RADIATOR
50
LOCK PULL TO FASTENER
50
LOCK , Replaced By: N912002008003
53
BOOT FAN SHROUD TO FAN RING
54
BOOT (SEALING LIP)
55
BRACKET SEALING LIP TO RADIATOR
56
BRACKET SEALING LIP TO OIL DIPSTICK BRACKET
56
BRACKET SEALING LIP TO OIL DIPSTICK BRACKET
57
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
58
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
58
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
59
BRACKET SEALING LIP TO EXPANSION TANK
60
PIN SEALING LIP TO EXPANSION TANK
61
TANK COOLING WATER EXPANSION
62
RADIATOR CAP FILLER NECK
62
RADIATOR CAP , Replaced By: A0005016415
63
SEAL RING
65
RADIATOR CAP
68
RADIATOR CAP CENTRAL
68
RADIATOR CAP CENTRAL
71
GASKET O.D., 52 MM
74
GASKET O.D., 37 MM
77
DRAIN PIPE
80
SENDER UNIT COOLING WATER LEVEL INDICATOR
83
PLATE FROM EXPANSION TANK TO RADIATOR
83
PLATE FROM EXPANSION TANK TO RADIATOR 40X40 MM
86
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
89
HOSE FROM EXPANSION TANK TO ENGINE
89
HOSE , Replaced By: A6565010382
92
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
92
CLAMP , Replaced By: N916017011001
98
BRACKET OIL DIPSTICK GUIDE TUBE
101
BRACKET OIL DIPSTICK GUIDE TUBE
104
SCREW , Replaced By: A6739900032
104
SCREW DE-AERATION LINE TO RADIATOR
107
CLAMP OIL-DIPSTICK GUIDE TUBE TO BRACKET
110
SCREW COVER PLATE TO BRACKET
110
SCREW , Replaced By: N304017008016
110
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
113
NUT , Replaced By: N913004006001
113
NUT PUMP TO BRACKET
113
NUT , Replaced By: N913004008001
113
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
113
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
