Поз.
Артикул
Описание
5
TANK OIL
5
TANK , Replaced By: A0004666202
8
OIL DIPSTICK
8
OIL DIPSTICK , Replaced By: A0004660867
11
FILLER CAP
11
FILLER CAP , Replaced By: A0004661268
14
SEAL RING
17
BRACKET
20
FILTER
20
FILTER
23
SCREW OIL TANK TO BRACKET
26
NUT , Replaced By: N913004006001
26
NUT PUMP TO BRACKET
29
BRACKET OIL TANK,5 593344
29
BRACKET OIL TANK,5 593344
32
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
38
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
41
CLAMP , Replaced By: N000000000667
41
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
44
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
44
LINE FROM OIL TANK TO HOSE
47
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
47
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
47
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
47
LINE FROM PUMP TO HIGH PRESSURE HOSE
47
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
47
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
50
UNION NUT LINE CONNECTION, Replaced By: N000000006243
50
NUT LINE CONNECTION
53
GLAND , Replaced By: A0019901267
53
SEAL CONE LINE CONNECTION
59
SCREW CONNECTION SUCTION LINE TO OIL PUMP, Replaced By: N000000006460
59
THREADED CONNECTION SUCTION LINE TO OIL PUMP
60
SCREW-IN FITTING SUCTION LINE TO OIL PUMP
61
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
62
FITTING DELIVERY LINE TO PUMP
65
LINE FROM PUMP TO HIGH PRESSURE HOSE
65
LINE FROM PUMP TO HIGH PRESSURE HOSE,K 073629K 114771
65
LINE FROM PUMP TO HIGH PRESSURE HOSE
65
LINE FROM PUMP TO HIGH PRESSURE HOSE
65
LINE FROM PUMP TO HIGH PRESSURE HOSE
65
LINE FROM PUMP TO HIGH PRESSURE HOSE
65
LINE FROM PUMP TO HIGH PRESSURE HOSE
68
UNION NUT LINE CONNECTION, Replaced By: N000000006239
68
UNION NUT LINE CONNECTION
71
GLAND , Replaced By: A0019901967
71
SEAL CONE LINE CONNECTION
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
77
LINE FROM HIGH PRESSURE HOSE TO STEERING
77
LINE FROM HIGH PRESSURE HOSE TO STEERING
77
LINE FROM HIGH PRESSURE HOSE TO STEERING
80
UNION NUT LINE CONNECTION, Replaced By: N000000006239
80
UNION NUT LINE CONNECTION
83
GLAND , Replaced By: A0019901967
83
SEAL CONE LINE CONNECTION
86
SCREW-IN FITTING DELIVERY LINE TO PUMP
86
FITTING DELIVERY LINE TO PUMP
89
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
92
LINE RETURN, FROM STEERING TO OIL TANK
92
LINE RETURN, FROM STEERING TO OIL TANK
92
LINE RETURN, FROM STEERING TO OIL TANK
92
LINE RETURN, FROM STEERING TO OIL TANK
92
LINE RETURN, FROM STEERING TO OIL TANK
95
UNION NUT LINE CONNECTION
98
GLAND LINE CONNECTION
101
HOSE DELIVERY LINE TO STEERING
104
CLAMP HOSE TO FITTING AND TO OIL TANK
104
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
110
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
113
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
116
BRACKET DELIVERY AND SUCTION LINES TO FRAME
116
BRACKET DELIVERY AND SUCTION LINES TO FRAME
119
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
119
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
122
NUT SUPPORT TO SIDE MEMBER
125
CLAMP DELIVERY AND SUCTION LINES TO STEERING
125
CLAMP , Replaced By: A6739950001
125
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
125
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
128
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
128
CLAMP DELIVERY AND SUCTION LINES TO FRAME
128
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
128
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
131
SCREW , Replaced By: N000000001422
131
SCREW , Replaced By: A0029903712
131
SCREW DELIVERY AND SUCTION LINES TO ENGINE, FRONT M 6X35
131
HEXALOBULAR BOLT CLAMP ON BRACKET M6X30
131
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
131
SCREW , Replaced By: N000000001149
134
SCREW , Replaced By: N000000001146
134
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
134
SCREW CLAMP MOUNTING M 6X16
137
NUT , Replaced By: N913004006001
137
NUT PUMP TO BRACKET
140
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
SCREW CENTRAL LOCK TO CAB M 10X16
999
WASHER
999
LINE FROM OIL TANK TO HOSE
999
BRACKET OIL TANK
999
BRACKET OIL TANK
999
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING
999
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
999
LINE FROM PUMP TO HIGH PRESSURE HOSE
999
LINE FROM PUMP TO HIGH PRESSURE HOSE
999
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
999
PROTECTIVE CAP
999
TUBE FROM HIGH PRESSURE HOSE TO STEERING
