Mercedes N000000006239 - НАКИДНАЯ ГАЙКА

1722,1824,2422 652.036

42 BRAKES - 150 MOUNTING OF LINES,HOSES,TEST CONNECTIONS

Поз.
Артикул
Описание
5
A3874601401
STEERING BOX ASSEMBLY FOR BREAK-DOWN,SEE UNIT STANDARD VERSIONMODEL: 765.300, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
A0005516156
TUBE FROM HIGH PRESSURE HOSE TO STEERING
11
N915017012100
UNION NUT LINE CONNECTION, Replaced By: N000000006239
11
N000000006239
UNION NUT LINE CONNECTION
14
N003861012007
GLAND , Replaced By: A0019901967
14
A0019901967
SEAL CONE LINE CONNECTION
17
A6564600424
LINE RETURN, FROM STEERING TO OIL TANK
20
N915017015100
UNION NUT LINE CONNECTION
23
N003861015004
GLAND LINE CONNECTION
26
A3874610240
STEERING SUPPORT
29
A6194630301
PITMAN ARM ,5 158233
32
A6554600435
BRACKET OIL TANK,5 593345
