Поз.
Артикул
Описание
260
STEERING SUPPORT HYDRAULIC CYLINDER TO FRAME
260
STEERING SUPPORT POWER CYLINDER
260
BEARING BRACKET POWER CYLINDER
263
SCREW BEARING TO CONSOLE
263
SCREW SUPPORT TO TRANSMISSION M 16X1.5X60
263
SCREW , Replaced By: N308676016005
263
SCREW FOLLOWER FLANGE TO PROPELLER SHAFT
263
SCREW , Replaced By: N308676016004
266
SPRING WASHER BRACKET TO TIMING CASE
269
NUT CONSOLE TO SUPPORT
269
NUT , Replaced By: N910113016001
272
CYLINDER (POWER CYLINDER),POWER STEERING
272
CYLINDER (POWER CYLINDER),POWER STEERING, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
272
CYLINDER , Replaced By: A0004662192
272
CYLINDER , Replaced By: A0004662192
275
DRAG LINK END R.H. THREAD
275
DRAG LINK ENDTO 000 466 27 92, 32 92, Replaced By: A0024600648
275
DRAG LINK END , Replaced By: A0014601648, +002A0019907651
275
DRAG LINK END POWER CYLINDER TO A 000 466 21 92
275
ARTICULATION PIECE POWER CYLINDER TO A 000 466 13 92
332
BLEEDER VALVE POWER STEERING CYLINDER
335
DRAG LINK END POWER CYLINDER LEMFOERDER
335
DRAG LINK END CYLINDER TO BEARING BRACKET AND TO INTERMEDIATE LEVER
338
CLAMP CLAMP, ONE-HOLE
341
SCREW CLAMP, ONE-HOLE
341
SCREW , Replaced By: N308676010017
344
HEXAGON NUT
344
NUT , Replaced By: N910113010002
347
NUT DRAG LINK TO LEVER
347
NUT LEVER TO TORSION BAR
350
COTTER PIN DRAG LINK TO LEVER
350
COTTER PIN6.3X63 MM
999
FITTING STEERING GEAR DELIVERY LINE,CIRCUIT II
999
GUIDE PISTON ROD GUIDE
999
THRUST WASHER ALSO INCLUDED IN GASKET KIT: 000 460 00 61
