Поз.
Артикул
Описание
5
TANK OIL
5
TANK , Replaced By: A0004666202
8
OIL DIPSTICK , Replaced By: A0004660867
8
OIL DIPSTICK
11
FILLER CAP , Replaced By: A0004661268
11
FILLER CAP
14
SEAL RING
17
BRACKET
20
FILTER
20
FILTER
23
SCREW OIL TANK TO BRACKET
26
NUT , Replaced By: N913004006001
26
NUT PUMP TO BRACKET
29
BRACKET OIL TANK
29
BRACKET OIL TANK, 650.282 AB IDENT-NO.: 5 963779 650.284 AB IDENT-NO.: K 020588
29
BRACKET , 650.282 AB IDENT-NO.: 5 963779 650.284 AB IDENT-NO.: K 020588, Replaced By: A6524600435
32
SCREW CENTRAL LOCK TO CAB M 10X16
38
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
41
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
41
CLAMP , Replaced By: N000000000667
44
LINE FROM OIL TANK TO HOSE, Replaced By: A0004291601
44
LINE , Replaced By: A0004291601
44
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
47
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
47
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
50
NUT LINE CONNECTION
50
UNION NUT LINE CONNECTION, Replaced By: N000000006243
53
GLAND , Replaced By: A0019901267
53
SEAL CONE LINE CONNECTION
59
SCREW-IN FITTING SUCTION LINE TO OIL PUMP
61
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
62
FITTING DELIVERY LINE TO PUMP
65
LINE FROM PUMP TO HIGH PRESSURE HOSE,5 549077
65
LINE FROM PUMP TO HIGH PRESSURE HOSE
65
LINE FROM PUMP TO HIGH PRESSURE HOSE
68
UNION NUT LINE CONNECTION
68
UNION NUT LINE CONNECTION, Replaced By: N000000006239
71
GLAND , Replaced By: A0019901967
71
SEAL CONE LINE CONNECTION
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
77
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING
77
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING
77
LINE RETURN, FROM STEERING TO OIL TANK
78
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
78
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX
78
LINE , Replaced By: A0005516256
80
UNION NUT LINE CONNECTION, Replaced By: N000000006239
80
UNION NUT LINE CONNECTION
83
GLAND , Replaced By: A0019901967
83
SEAL CONE LINE CONNECTION
86
SCREW-IN FITTING DELIVERY LINE TO PUMP
89
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
90
SCREW CONNECTION RETURN, FROM STEERING TO OIL TANK
91
SEAL RING VALVE TO VALVE,K 025179
95
UNION NUT LINE CONNECTION
98
GLAND LINE CONNECTION
101
HOSE DELIVERY LINE TO STEERING
104
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
104
CLAMP HOSE TO FITTING AND TO OIL TANK
116
BRACKET DELIVERY AND SUCTION LINES TO FRAME
119
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
122
NUT SUPPORT TO SIDE MEMBER
125
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
125
CLAMP DELIVERY AND SUCTION LINES TO STEERING
125
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
125
CLAMP , Replaced By: A6739950001
125
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
128
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
128
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
128
CLAMP DELIVERY AND SUCTION LINES TO FRAME
128
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
131
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
131
SCREW CAB FLOOR COVERING M 6X25
131
SCREW , Replaced By: N000000001149
131
SCREW , Replaced By: A0029903712
133
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
134
SCREW , Replaced By: N000000001146
134
SCREW VALVE TO BRACKET,5 465030
134
SCREW CLAMP MOUNTING M 6X16
134
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
136
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
136
WASHER COMPRESSED AIR LINE TO BRACKET
137
NUT , Replaced By: N913004006001
137
NUT PUMP TO BRACKET
999
THRUST RING SUCTION LINE TO OIL PUMP
999
TUBE FROM HIGH PRESSURE HOSE TO STEERING
999
SEALING CORD SUCTION LINE TO OIL PUMP
999
PROTECTIVE CAP
999
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
999
LINE , Replaced By: A0005516156
999
BRACKET LINE MOUNTING
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE
999
ELBOW FITTING SUCTION LINE TO OIL PUMP
999
SCREW BRACKET TO FRAME SIDE MEMBER
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
NUT SUCTION LINE TO OIL PUMP
999
NUT STRAP TO BRACKET
999
NUT , Replaced By: N910113010000
