Поз.
Артикул
Описание
5
CONNECTOR FRONT EXHAUST PIPE,LEFT
5
INTERMEDIATE PIECE FRONT EXHAUST PIPE,LEFT
5
CONNECTOR FRONT EXHAUST PIPE,LEFT
5
CONNECTOR FRONT EXHAUST PIPE,LEFT
15
CONNECTOR FRONT EXHAUST PIPE,RIGHT
15
INTERMEDIATE PIECE FRONT EXHAUST PIPE,RIGHT
15
CONNECTOR FRONT EXHAUST PIPE,RIGHT
15
CONNECTOR FRONT EXHAUST PIPE,RIGHT
20
SCREW CONNECTOR TO EXHAUST MANIFOLD
25
NUT CONNECTOR TO EXHAUST MANIFOLD
30
FLEXIBLE METAL TUBE FRONT
30
FLEXIBLE METAL TUBE FRONT LEFT
30
FLEXIBLE METAL TUBE CONNECTOR
35
CONNECTOR EXHAUST LINE FLEXIBLE METAL TUBE
35
COLLAR (SLIDING COLLAR)
35
COLLAR EXHAUST LINE FLEXIBLE METAL TUBE
40
CLAMP FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
40
CLAMP FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
65
BRACKET RIGHT, TO BE ADAPTED DURING ASSEMBLY
65
BRACKET LEFT
67
BRACKET AT SIDE MEMBER
70
BRACKET RIGHT EXHAUST PIPE
70
BRACKET LEFT EXHAUST PIPE
70
BRACKET , Replaced By: A6194920441
75
BRACKET AT SIDE MEMBER
85
BRACKET LEFT EXHAUST PIPE
90
BRACKET RIGHT EXHAUST PIPE
95
CLAMP EXHAUST PIPE TO BRACKET
95
CLAMP FLEXIBLE METAL TUBE TO EXHAUST PIPE
999
BRACKET BRACKET TO EXHAUST PIPE
999
BRACKET BRACKET TO EXHAUST PIPE
999
SUPPORT EXHAUST MUFFLER,LEFT
999
SUPPORT EXHAUST MUFFLER,RIGHT
