Поз.
Артикул
Описание
5
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
8
UNION NUT LINE CONNECTION
11
GLAND LINE CONNECTION
14
FITTING ENGINE AIR COMPRESSOR,CONNECTION: "20"
17
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
20
ELBOW FITTING , Replaced By: A0039901671
20
ELBOW FITTING ENGINE AIR COMPRESSOR,CONNECTION: "20", Replaced By: A6209900071
20
ELBOW FITTING , Replaced By: A0039901671
23
SEAL RING ENGINE AIR COMPRESSOR,CONNECTION: "20"
26
SEAL RING LINE CONNECTION
29
THRUST RING SUCTION LINE TO OIL PUMP
32
NUT SUCTION LINE TO OIL PUMP
35
BRACKET 3/2-WAY SOLENOID VALVE
35
BRACKET , Replaced By: A6454200486
999
BRACKET COMPRESSED AIR LINE TO ENGINE
