Поз.
Артикул
Описание
5
OIL PIPE FEED, OIL COOLER,5 564482K 093236
5
OIL PIPE FEED, OIL COOLER,K 093237K 131865
5
PIPE FEED, OIL COOLER
8
OIL PIPE RETURN, OIL COOLER,K 093236
8
OIL PIPE RETURN, OIL COOLER,K 093237K 131865
8
PIPE RETURN, OIL COOLER,K 131866
11
HOSE FEED, OIL COOLER,K 131866
11
HOSE OIL COOLER CONNECTION,K 131865
11
HOSE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6559972482
14
HOSE RETURN, OIL COOLER,K 131866
14
HOSE OIL COOLER CONNECTION,K 131865
14
HOSE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6559972582
17
CLAMP LINE MOUNTING
20
BRACKET BELL HOUSING
25
BRACKET AT ENGINE, FROM IDENT NO. 5 623090, SEE STANDARD MICROFICHEK 131865
27
BRACKET AT ENGINE
29
CLAMP FEED LINE TO THERMOSTAT
29
CLAMP , Replaced By: A3609950601
32
SCREW PIPE CLAMP
32
SCREW , Replaced By: N304017008021
32
SCREW LICENSE PLATE TO BRACKET
32
SCREW , Replaced By: N304017006020
35
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
35
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
35
NUT , Replaced By: N913004008001
35
NUT PUMP TO BRACKET
35
NUT , Replaced By: N913004006001
