Поз.
Артикул
Описание
5
REAR SPRING (PARABOLIC SPRING),3-LEAF, WITH 2-LEAF HELPER SPRING,K 083474
5
REAR SPRING (PARABOLIC SPRING),3-LEAF, WITH 2-LEAF HELPER SPRING,K 083473
8
BUSHING
8
BUSHING
9
RUBBER MOUNTING ,K 062675
9
RUBBER MOUNTING ,K 062675
9
RUBBER MOUNTING ,K 062675
11
SPACER REAR SPRING
14
SHIM REAR SPRING
17
SPRING CLAMP REAR SPRING
20
RIVET SPRING CLAMP TO SPRING LEAF,5 940410
23
SPACER TUBE SPRING CLAMP
26
SCREW STRUT TO BUMPER
26
SCREW , Replaced By: A0079900601
29
NUT SUPPORT TO SIDE MEMBER
35
SPRING BOLT
38
NUT TORSION BAR TO BEARING BRACKET,5 904661
122
PIN BEARING BRACKET
125
PAD BETWEEN SPRING AND REAR AXLE
128
SPRING CLAMPING PLATE REAR SPRING TO REAR AXLE
128
SPRING CLAMPING PLATE REAR SPRING TO REAR AXLE
131
U-BOLT REAR AXLE TO TO REAR SPRINGS 500 MM,4 941582
131
U-BOLT , Replaced By: A6203510125
134
WASHER STEEL VERSION
134
WASHER CAST VERSION
137
BEARING TORSION BAR AND SHOCK ABSORBER,LEFT
137
BEARING TORSION BAR AND SHOCK ABSORBER,RIGHT
146
NUT REAR SPRING TO REAR AXLE
149
SHACKLE REAR SPRING
149
SHACKLE , Replaced By: A6213250020, +002A3353240050
152
BUSHING
155
GREASE NIPPLE FOR SPRING
156
SHACKLE REAR SPRING,K 083474
156
SHACKLE THREADED,K 083474
158
THRUST WASHER SHACKLE TO REAR-SPRING REAR BRACKET, INSIDE
161
THRUST WASHER SHACKLE TO REAR-SPRING REAR BRACKET, OUTSIDE
164
SEAL RING SHACKLE TO REAR-SPRING REAR BRACKET
167
NUT SHACKLE TO REAR-SPRING REAR BRACKET
170
SHACKLE PIN (PARTS KIT),FRONT SPRING EYE
170
SHACKLE PIN (PARTS KIT),REAR SPRING EYE, ON RELOCATION OF SPRING SHACKLES,SUPPLY ADDITIONALLY:2X 335 324 00 50
171
SCREW FRONT SPRING TO FRONT SPRING FRONT BRACKET
172
BUSHING FRONT SPRING TO FRONT SPRING FRONT BRACKET,K 083474
174
SCREW FRONT SPRING TO SPRING SHACKLE
176
GREASE NIPPLE PROTECTIVE TUBE
179
WASHER FRONT SPRING TO SPRING SHACKLE & SPRING BRACKETS
179
WASHER SHACKLE PIN, AS REQUIRED 4.0 MM
182
SEAL RING SPRING SHACKLE TO SPRING REAR BRACKET
185
BOLT SPRING SHACKLE TO SPRING REAR BRACKET
188
WASHER , Replaced By: N000125010532
188
WASHER RADIATOR TO RUBBER MOUNTING
191
NUT STRAP TO BRACKET
191
NUT , Replaced By: N910113010000
