Поз.
Артикул
Описание
41
BUSHING ROHRLEITUNG AN ZYLINDERKOPF, USED WITH AUTOMATIC TRANSMISSION
41
CLAMPING SLEEVE SENSOR TO STEERING KNUCKLE
41
LOCK , Replaced By: A9755420050
44
SEAL RING RPM SENSOR ON TIMING CASE, RECOMMENDED FOR TAKING ON STOCK*0052774
47
SEAL RING
50
BRACKET SPEED SENDER UNIT
53
SCREW , Replaced By: A9060150071
53
SCREW ,189564/91
56
WASHER COMPRESSED AIR LINE TO BRACKET
62
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
65
HEXAGON HEAD BOLT BELLOWS TO BRACKET M8X12
65
SCREW CLAMP ON BRACKET
71
PLUG SOCKET. PLUG HOUSING
71
SOCKET HOUSING
74
ROUND PIN BUSHING0.5-1.0 MM2
74
ROUND PIN BUSHING
80
WIRE SEAL GREY 0.5-1.0 MM2
80
GASKET. BLIND PLUG
83
BOOT PLUG-IN CONNECTION,FUEL GAUGE SENSOR
89
PARTS KIT FUEL GAUGE SENDER UNIT, THIS CABLE HARNESS IS A COMPONENT OF FRAME MOUNTED CABLE HARNESS ASSEMBLY AND CAN BE MADE AVAILABLE AS A SPARE ATTENTION: WHEN PLACING ORDERS, PLEASE QUOTE VEHICLE IDENT NO. ONLY IF FRAME MOUNTED CABLE HARNESS IS REQUIRED AS AN ASSEMBLYK 171434
89
PLUG HOUSING
92
NUT FROM ELECTRICAL COMPARTMENT TO CONTROL UNIT,SENSOR,ABS SOLENOID VALVE
95
GASKET LIGHT BLUE 8 MM
98
ROUND PIN BUSHING0.5-1.0 MM2
98
CONTACT BUSHING. ROUND PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 0.5-1.0 MM2
101
BOOT
104
PIN BUSHING FLAME START SYSTEM R3.2
107
NUT RELAY TO BRACKET M5
194
PIN BUSHING HOUSING WITH FIFTY-FOUR PINS,ABS ELEKTRONIK
197
CONTACT SPRING LESS DETENT,BUT WITH CATCH FOR HOUSING 0.5-1.0MM2,126372
200
CABLE SEAL. GASKET CONTROL-UNIT PLUG-CONNECTION
203
CAP PIN BUSHING HOUSING,FIFTY-FOUR PIN
206
STOP PLUG. PLUG CONTROL-UNIT PLUG-CONNECTION
206
SPRING CONTROL MODULE ON CRANKCASE
221
CABLE SHOE
242
PARTS KIT. PLUG SOCKET (PARTS KIT),HEAT RESISTANT,BIPOLAR SCREW CONNECTION,FOR INSULATING HOSE M 24X1
245
TS PLUG REFRIGERANT TEMPERATURE SENDER UNIT
245
PLUG FUEL TEMPERATURE
251
PLUG OIL LEVEL SENDER UNIT
251
TS PLUG START-STOP SWITCH
254
PLUG AGN HWL TANK HEATER
257
COUPLING. PLUG CONNECTION FOR CONSTANTLY-OPEN THROTTLE VALVE
257
PLUG AGN HWL METERING VALVE
260
PLUG AGN COMPRESSED AIR SENSOR
260
PLUG CHARGE AIR TEMPERATURE SENSOR
260
PLUG BOOST AIR COMBINATION SENSOR
260
PLUG HEATER FLANGE
263
CORRUGATED HOSE ADAPTER. ADAPTER BOOST AIR COMBINATION SENSOR
266
TS PLUG. PLUG PARTS KIT
269
TS PLUG OIL PRESSURE COMBINATION SENSOR
275
PARTS KIT PLUG CONNECTION,TACHOGRAPH SENSOR X36, 4PIN, TO BE ADAPTED DURING ASSEMBLY
278
TS SOCKET PARTS KIT. PLUG SOCKET 7-POLE
281
BOOT
284
PLUG SOCKET BRANCH-OFF TO FUEL GAUGE SENDER UNIT
287
STOP PLUG. PLUG CONTROL-UNIT PLUG-CONNECTION
290
CONNECTOR I.D.: 22, 90°
290
CONNECTOR90/22/22
293
DISTRIBUTOR I.D.: 7,5-7,5-7,5,*0030467
296
DISTRIBUTOR I.D.: 10/10/10
296
DISTRIBUTOR I.D.: 17/17/13,*0109390
296
DISTRIBUTOR I.D.: 17/17/17,*0109390
296
DISTRIBUTOR10/10/10
296
DISTRIBUTOR I.D.: 10/7,5/10
296
DISTRIBUTOR I.D.: 22/10/22
296
DISTRIBUTOR I.D.: 22/22/22
296
DISTRIBUTOR22/22/10
296
DISTRIBUTOR I.D.: 22/22/10
296
DISTRIBUTOR I.D.: 22/7,5/22
296
DISTRIBUTOR I.D.: 10/4,5/10
296
DISTRIBUTOR I.D.: 10/7,5/7,5
296
DISTRIBUTOR7,5/7,5/7,5
299
DISTRIBUTOR I.D.: 17/17,*0109390
305
DISTRIBUTOR I.D.: 13/7,5/7,5,064001
305
DISTRIBUTOR I.D.: 7,5/7,5/7,5
308
REDUCER I.D.: 22/17
308
REDUCTION FITTING I.D.: 10/4,5
308
REDUCER I.D.: 10/7,5
323
SPEED SENDER UNIT CRANKSHAFT
323
SPEED SENDER UNIT CAMSHAFT,*0030447*0094097, Replaced By: A0001539520
323
SPEED SENDER UNIT CRANKSHAFT
323
SPEED SENDER UNIT ON FLYWHEEL HOUSING UPPER RING GEAR
326
BRACKET SPEED SENDER UNIT,067700
330
BOOT ON AIR DRIER
