Поз.
Артикул
Описание
10
SENDER UNIT FUEL GAUGE, UP TO IDENT NO. K 169122, FROM IDENT NO. SEE STANDARD VERSION
10
SENDER UNIT FUEL GAUGE, UP TO IDENT NO. K 169122, FROM IDENT NO. SEE STANDARD VERSION
10
SENDER UNIT FUEL GAUGE, UP TO IDENT NO. K 169122, FROM IDENT NO. SEE STANDARD VERSION
10
SENDER UNIT FUEL GAUGE, UP TO IDENT NO. K 169122, FROM IDENT NO. SEE STANDARD VERSION
15
PLASTIC PIPE RISING PIPE 4X6 MM
15
HOSE FUEL LINE, ORDER BY THE METER
15
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
20
HOSE LEAK LINE, ORDER BY THE METER
25
INTERMEDIATE PIECE FUEL LINE,K 223528
30
BRACKET LINE MOUNTING
35
LOOM TIE LINE MOUNTING
40
CLAMP LINE MOUNTING
45
AUXILIARY PUMP AUXILIARY HEATER,K 169122
45
AUXILIARY PUMP AUXILIARY HEATER,K 169123
50
FITTING
55
STRAINER
60
BRACKET ADDITIONAL FUEL PUMP
60
BRACKET ADDITIONAL FUEL PUMP
65
SCREW PUMP TO BRACKET
65
SCREW , Replaced By: N304017006016
70
NUT , Replaced By: N913004006001
70
NUT PUMP TO BRACKET
75
CLAMP PUMP TO BRACKET
80
LOOM TIE LINE MOUNTING 280 MM
80
LOOM TIE LINE MOUNTING
999
CLAMP LINE MOUNTING SA 088202/01
999
BANJO UNION HEATING CONNECTION,K 169122
999
HOLLOW SCREW , Replaced By: N915036010108
999
HOLLOW SCREW FUEL LINE TO FEED PUMP
999
SEAL RING FUEL LINE TO FEED PUMP
999
RISING PIPE FUEL TANK
999
SENDER UNIT
999
SENDER UNIT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 169122, Replaced By: A0115426717, +001A0005409917
999
SENDER UNIT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 169122, Replaced By: A0115426317, +001A0005409917
999
SENDER UNIT , Replaced By: A0115426617, +001A0005409917
999
SENDER UNIT FUEL GAUGE
999
SENDER UNIT FUEL GAUGE
999
CONNECTOR
999
COVERING RISING PIPE,K 169122
