Поз.
Артикул
Описание
5
PROTECTIVE RAIL UNDERRUN PROTECTION,LEFT 4590 MM, TO BE ADAPTED DURING ASSEMBLY
5
PROTECTIVE RAIL , Replaced By: A6525251182
5
PROTECTIVE RAIL , Replaced By: A6525250482
6
BUMPERETTE RAIL
6
BUMPERETTE RAIL
6
BUMPERETTE RAIL
6
BUMPERETTE RAIL
8
CAP LEFT AND RIGHT,FRONT AND REAR
11
CAP UNDERRUN PROTECTION
11
COVER UNDERRUN PROTECTION
14
BRACKET UNDERRUN PROTECTION
17
BRACKET UNDERRUN PROTECTION
20
STAY UNDERRUN PROTECTION
22
BRACKET UNDERRUN PROTECTION
22
BRACKET UNDERRUN PROTECTION
24
ANGLE , Replaced By: A3184280240
24
BRACKET LINE MOUNTING
24
BRACKET LINE MOUNTING
26
SCREW , Replaced By: N304017008021
26
SCREW PIPE CLAMP
26
SCREW PIPE CLAMP
28
SCREW , Replaced By: N304017008016
28
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
28
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
28
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
30
WASHER , Replaced By: N000125008443
30
WASHER EXHAUST MUFFLER TO STRAP
30
WASHER EXHAUST MUFFLER TO STRAP
30
WASHER EXHAUST MUFFLER TO STRAP
30
WASHER EXHAUST MUFFLER TO STRAP
30
WASHER EXHAUST MUFFLER TO STRAP
32
NUT , Replaced By: N913004008001
32
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
32
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
32
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
32
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
32
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
32
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
32
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
32
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
32
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
34
SCREW , Replaced By: N308676012012
34
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
36
WASHER
38
SCREW , Replaced By: N304017008016
38
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
38
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
38
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
38
WASHER
39
SCREW CAP TO RAIL AM 8X40
40
SCREW EXHAUST MUFFLER TO STRAP
40
SCREW EXHAUST MUFFLER TO STRAP
40
SCREW , Replaced By: N304017008040
40
SCREW BRACKET TO SIDE MEMBER
40
SCREW BRACKET TO SIDE MEMBER
42
WASHER EXHAUST MUFFLER TO STRAP
42
WASHER EXHAUST MUFFLER TO STRAP
42
WASHER EXHAUST MUFFLER TO STRAP
42
WASHER EXHAUST MUFFLER TO STRAP
42
WASHER EXHAUST MUFFLER TO STRAP
42
WASHER , Replaced By: N000125008443
44
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
44
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
44
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
44
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
44
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
44
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
44
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
44
NUT , Replaced By: N913004008001
44
WASHER EXHAUST MUFFLER TO STRAP
44
WASHER EXHAUST MUFFLER TO STRAP
44
WASHER , Replaced By: N000125008443
46
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
46
SCREW END PIECE TO EXHAUST PIPE M 10X25
46
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
48
NUT STRAP TO BRACKET
48
NUT , Replaced By: N910113010000
50
SCREW BUSHING AND LEVER TO CAB
50
SCREW BUSHING AND LEVER TO CAB
52
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
52
NUT , Replaced By: N913004008001
54
REFLECTOR FENDER
54
REFLECTOR FENDER
54
REFLECTOR REAR LEFT AND RIGHT
54
REFLECTOR REAR LEFT AND RIGHT
54
REFLECTOR AMBER
54
REFLECTOR AMBER
56
SCREW REFLECTOR TO UNDERRUN PROTECTION
58
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
58
WASHER , Replaced By: N009021005205
59
NUT TWO-WAY VALVE TO BRACKET
999
STAY UNDERRUN PROTECTION, NOT USED
999
STAY UNDERRUN PROTECTION, NOT USED
999
STAY UNDERRUN PROTECTION, NOT USED
