Поз.
Артикул
Описание
5
SWITCHING APPARATUS ENGINE CONTROL
5
SWITCHING APPARATUS ENGINE CONTROL
10
BRACKET ENGINE CONTROL
15
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
20
FOLLOWER ENGINE CONTROL
25
COVERING INTERMEDIATE BEARING
30
LEVER ENGINE CONTROL
35
SCREW BRACKET ON LOAD SENSOR M 5X30
40
BALL PIVOT LOAD SENSOR
45
WASHER COMPRESSED AIR LINE TO BRACKET
45
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
50
NUT PUMP TO BRACKET
50
NUT , Replaced By: N913004006001
50
NUT TWO-WAY VALVE TO BRACKET
55
SCREW UNDERRUN PROTECTION AND BRACKET TO FRAME M 10X70
60
NUT BRACKET TO SUPPORT AND TO END PIECE
65
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
70
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
70
NUT , Replaced By: N913004008001
70
NUT PUMP TO BRACKET
70
NUT , Replaced By: N913004006001
75
SPRING AT CONTROL LEVER
80
PULL ROD LOAD SENSOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
85
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
90
NUT BALL PIVOT TO LEVER
