Поз.
Артикул
Описание
5
GROMMET42/36 MM, NOT USED
8
GROMMET LINE PASSAGE AT SIDE MEMBER 32/27 MM
11
GROMMET LINE THRU FRAME
14
WASHER BRACKET TO LEFT SIDE MEMBER
17
BRACKET RIGHT COMPRESSED AIR LINES
17
BRACKET RIGHT COMPRESSED AIR LINES, Replaced By: A6554303410
17
BRACKET LEFT COMPRESSED AIR LINES
17
BRACKET LEFT COMPRESSED AIR LINES, Replaced By: A6554303310
17
BRACKET LEFT COMPRESSED AIR LINES, Replaced By: A6554200786
20
BRACKET COMPRESSED AIR LINE TO ENGINE BEARING BRACKET
23
SCREW PIPE CLAMP
23
SCREW , Replaced By: N304017008021
26
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
26
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
26
NUT , Replaced By: N913004008001
27
WASHER EXHAUST MUFFLER TO STRAP
27
WASHER , Replaced By: N000125008443
29
BRACKET COMPRESSED AIR LINE TO ENGINE BEARING BRACKET
29
BRACKET COMPRESSED AIR LINE TO ENGINE BEARING BRACKET
29
BRACKET , Replaced By: A6154200086
32
SCREW BRACKET TO CROSS CONNECTION STRUT
32
SCREW , Replaced By: N304017008034
35
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
35
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
35
NUT , Replaced By: N913004008001
38
BRACKET BREATHER LINE TO SIDE MEMBER
41
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
41
SCREW , Replaced By: N304017008027
44
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
44
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
44
NUT , Replaced By: N913004008001
47
BRACKET LINE TO FRONT PANEL, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 115008, Replaced By: A0002930040
47
BRACKET LINE TO FRONT PANEL, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 115008, Replaced By: A0002930040
48
BRACKET LINE TO FRONT PANEL
49
EDGE GUARD SECTION AT SHOCK ABSORBER BRACKET, ORDER BY THE METER
49
EDGE GUARD SECTION , Replaced By: A0019872272
50
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
50
WASHER , Replaced By: N009021005205
53
NUT BRACKET TO PIN
56
BRACKET FUEL LINES TO TRANSMISSION
62
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
65
NUT STRAP TO BRACKET
65
NUT , Replaced By: N910113010000
66
BRACKET BRACKET TO CONTROL ARM
66
BRACKET , NOT USED, Replaced By: A6554314640
66
BRACKET , Replaced By: A6554314640
67
SHEET METAL SCREW CABLE MOUNTING IN CABLE DUCT, NOT USED
69
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
70
BRACKET AIR RESERVOIR TO APPARATUS SUPPORT
72
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
74
NUT STRAP TO BRACKET
74
NUT , Replaced By: N910113010000
77
LINE FROM FITTING TO RIGHT DIAPHRAGM CYLINDER
78
CLAMP COMPRSSED AIR LINE TO SUBSTRUCTURE
79
BRACKET LINE MOUNTING 11 MM
79
CLAMP , Replaced By: A0004760436
80
CLAMP 3/2-WAY SOLENOID VALVE
81
CLIP COMPRSSED AIR LINE TO SUBSTRUCTURE
83
SCREW CLAMP TO BRACKET
83
SCREW CLAMP TO BRACKET, Replaced By: N007985006581
86
WASHER COMPRESSED AIR LINE TO BRACKET
86
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
89
NUT PUMP TO BRACKET
89
NUT , Replaced By: N913004006001
92
HOSE FRONT AND REAR AXLE BRAKE CYLINDERS 11 MM
95
FITTING DIAPHRAGM CYLINDER,CONNECTION:
98
UNION NUT LINE CONNECTION
98
UNION NUT LINE CONNECTION, Replaced By: N000000006239
101
GLAND , Replaced By: A0019901967
101
SEAL CONE LINE CONNECTION
104
CLAMP HOSE TO FITTING AND TO OIL TANK
104
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
107
ADAPTER FITTING LINE CONNECTION TO ENGINE
110
NUT BRACKET TO SIDE MEMBER
110
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
113
T-FITTING LEFT AND RIGHT BRAKE HOSES
113
T-FITTING DIAPHRAGM CYLINDER
116
SCREW. UNION SCREW LINE CONNECTION
119
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
122
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
125
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
128
FITTING DELIVERY LINE TO PUMP
128
ELBOW FITTING TRAILER CONTROL VALVE,CONNECTION: 1.1
134
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
135
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
136
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
137
CONNECTOR FROM REAR BRAKE HOSE TO TRISTOP CYLINDER TO M 22
137
CONNECTOR FROM REAR BRAKE HOSE TO TRISTOP CYLINDER TO M 22
140
CONNECTOR HOSE WIDTH, 9 MM, TO M 22
143
LOCK REAR AXLE BRAKE HOSE,K 181360
146
CLAMP HOSE TO FITTING AND TO OIL TANK
146
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
152
TEST CONNECTION
152
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
152
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
152
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
155
LOOM TIE LINE MOUNTING
155
LOOM TIE LINE MOUNTING 280 MM
