Поз.
Артикул
Описание
200
HOSE FROM RADIATOR TO THERMOSTAT
200
HOSE FROM RADIATOR TO THERMOSTAT
200
HOSE FROM RADIATOR TO THERMOSTAT
200
HOSE FROM RADIATOR TO THERMOSTAT
205
CLAMP , Replaced By: N000000000674
205
CLAMP HOSE 70-90X13 MM
205
CLAMP , Replaced By: N000000000671
205
CLAMP SUCTION LINE TO OIL PUMP 40-60X13 MM
210
BRACKET HOSE TO RADIATOR AND TO WATER PUMP,5 422023
215
PIPE ELBOW AT WATER PUMP,5 510518
220
HOSE FROM RADIATOR OUTLET TO WATER PUMP
220
HOSE FROM RADIATOR OUTLET TO WATER PUMP
220
HOSE FROM RADIATOR TO WATER PUMP,5 193595
225
HOSE FROM RADIATOR OUTLET TO WATER PUMP
225
HOSE FROM RADIATOR OUTLET TO WATER PUMP
225
HOSE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 510825 5 510826, Replaced By: A6505012782, +001A6505060940
225
HOSE FROM RADIATOR OUTLET TO WATER PUMP
225
HOSE FROM RADIATOR OUTLET TO WATER PUMP
230
HOSE FROM RADIATOR OUTLET TO WATER PUMP, ORDER BY THE METER
235
CLAMP , Replaced By: N000000000674
235
CLAMP HOSE 70-90X13 MM
240
CLAMP , Replaced By: N000000000667
240
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
240
CLAMP , Replaced By: N000000000670
245
CONNECTOR FOR SCREW FITTING
245
CONNECTOR FROM ENGINE TO EXPANSION TANK
245
CONNECTOR FROM ENGINE TO EXPANSION TANK
245
CONNECTOR AT WATER PUMP
245
CONNECTOR AT WATER PUMP
250
CONNECTOR FEED LINE TO ENGINE
255
FLANGE ENGINE BREATHING
260
GASKET. SEAL DE-AERATION PIPE TO ENGINE
265
GASKET , Replaced By: A4422010480
265
GASKET CONNECTOR, Replaced By: A0002011080
265
GASKET CONNECTOR, Replaced By: A0002011180
265
GASKET CONNECTOR, Replaced By: A0002011280
265
GASKET CONNECTOR
270
SCREW END PIECE TO EXHAUST PIPE M 10X25
270
SCREW END PIECE TO EXHAUST PIPE M 10X25
270
SCREW STRAP TO BRACKET
275
SCREW , Replaced By: N304017010050
275
SCREW , Replaced By: N304017010055
275
SCREW CLUTCH TO FLYWHEEL
280
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
285
SCREW , Replaced By: N304017010030
285
SCREW , Replaced By: N304017010053
285
SCREW PIPE ELBOW TO BRACKET M 10X50
290
NUT , Replaced By: N910113010000
290
NUT STRAP TO BRACKET
295
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
295
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
302
CLAMP , Replaced By: N000000000670
305
HOSE DE-AERATION PIPE TO EXPANSION TANK
310
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
310
HOSE DE-AERATION PIPE TO EXPANSION TANK
310
HOSE DE-AERATION PIPE TO EXPANSION TANK
315
HOSE DE-AERATION PIPE TO EXPANSION TANK
320
HOSE FROM FLANGE TO DE-AERATION PIPE
325
CLAMP HOSE TO FITTING AND TO OIL TANK
325
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
325
CLAMP , Replaced By: N000000000667
325
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
325
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
340
BREATHER PIPE ENGINE BREATHING
340
BREATHER PIPE FROM ENGINE TO EXPANSION TANK
345
BREATHER PIPE ENGINE BREATHING
350
ANGLE LINE MOUNTING
355
CLAMP , Replaced By: A6739950001
355
CLAMP DELIVERY AND SUCTION LINES TO STEERING
385
NUT , Replaced By: N913004006001
385
NUT PUMP TO BRACKET
385
NUT PUMP TO BRACKET
428
NUT RETAINER , Replaced By: A0019906791
428
NUT RETAINER LICENSE PLATE TO BRACKET
445
SCREW , Replaced By: N304017006016
445
SCREW PUMP TO BRACKET
445
SCREW PUMP TO BRACKET
999
SCREW WATER DRAIN
999
LOCK
999
PIN SEALING LIP TO EXPANSION TANK
999
BRACKET SEALING LIP TO EXPANSION TANK
999
SEAL RINGTO 000 553 03 05,000 553 18 05,
