Поз.
Артикул
Описание
16
TRAVEL SENSOR REAR AXLE,K 186868
17
SCREW VALVE TO BRACKET, Replaced By: N304014008002
17
SCREW VALVE TO BRACKET
18
NUT , Replaced By: A0009906350
18
NUT , Replaced By: N913004008001
18
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
24
LEVER , Replaced By: A9453200627
24
LEVER TRAVEL SENSOR, TO BE ADAPTED DURING ASSEMBLY
24
LEVER TRAVEL SENSOR, TO BE ADAPTED DURING ASSEMBLY
32
BALL STUD. BALL PIVOT TOP B10X4,5 MM
32
BALL STUD. BALL PIVOT TOP B10X4,5 MM
36
SCREW , Replaced By: N304017006018
36
SCREW COVER PLATE TO COVER PLATE M 6 X 12
44
ROD ,K 166016, Replaced By: A0003290930, +001A0003291030, +001N304032008006, +001N304032008007, +001N900331008427
44
ROD , Replaced By: A0003290930, +001A0003291030, +001N304032008006, +001N304032008007, +001N900331008427
44
ROD , Replaced By: A0003290930, +001A0003291030, +001N304032008006, +001N304032008007, +001N900331008427
44
ROD , Replaced By: A0003290930, +001A0003291030, +001N304032008006, +001N304032008007, +001N900331008427
44
ROD TRAVEL SENSOR
45
NUT , Replaced By: A0009906350
132
VALVE REAR AXLE SELF-LEVELLING DEVICE
132
VALVE , Replaced By: A0049975736
132
VALVE (3/2-WAY SOLENOID VALVE) EKS
132
VALVE (3/2-WAY SOLENOID VALVE) WABCO
132
VALVE (3/2-WAY SOLENOID VALVE) KNORR
139
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION,5 9363665 812731
140
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
141
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
144
SCREW. UNION SCREW LINE CONNECTION
148
SCREW PLUG , Replaced By: N000908022011
148
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
148
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
152
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
152
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
156
BRACKET AIR SPRING VALVE
156
BRACKET ,5 760168 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 962043, Replaced By: A6523270440
160
SCREW , Replaced By: N304017008053
160
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
164
NUT , Replaced By: N913004008001
164
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
164
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
168
SCREW , Replaced By: N304017008034
168
SCREW BRACKET TO CROSS CONNECTION STRUT
168
SCREW , Replaced By: N304017008021
168
SCREW PIPE CLAMP
999
PULL ROD PNEUMATIC SUSPENSION CONTROL
999
NUT BALL SOCKET TO ROD
999
NUT
999
SCREW PLUGROCKINGER,TYP 59 U150
999
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
999
SEAL RING LINE CONNECTION
999
FITTING FROM PUMP TO CYLINDER
999
CYLINDER REAR AXLE SELF-LEVELLING DEVICE
999
BRACKET TEST CONNECTION
999
LEVER AIR SPRING VALVE,5 760167
999
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
999
PROTECTIVE CAPWABCO
999
MAGNET ,5 760168K 154651
999
AIR CLEANER ,5 760168K 154651
999
REPAIR KITTO 388 997 88 36
999
BALL JOINT LEFT-HAND THREAD,BALL DIAMETER 10 MM
999
BALL JOINT TRAVEL SENSOR
