Поз.
Артикул
Описание
5
WIRE CABLE MANUAL CONTROL, REPAIR IMPOSSIBLE
5
WIRE CABLE MANUAL CONTROL
8
FITTED WASHER WIRE CABLE TO INSTRUMENT PANEL
11
NUT WIRE CABLE TO INSTRUMENT PANEL
14
KNOB IDLING ADJUSTMENT
17
CLAMPING PIECE IDLING ADJUSTMENT WIRE CABLE
18
CLAMP ,K 147121, Replaced By: N000000000319
18
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
20
SCREW , Replaced By: A0029903712
20
SCREW , Replaced By: N000000001149
20
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
23
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
23
WASHER COMPRESSED AIR LINE TO BRACKET
26
NUT , Replaced By: N913004006001
26
NUT PUMP TO BRACKET
32
BRACKET WIRE CABLE TO FRAME SIDE MEMBER
44
BRACKET WIRE CABLE TO FRAME SIDE MEMBER
44
BRACKET WIRE CABLE TO FRAME SIDE MEMBER
44
BRACKET WIRE CABLE TO FRAME SIDE MEMBER
53
BRACKET WIRE CABLE TO HYDRAULIC LINE BRACKET
56
SCREW LICENSE PLATE TO BRACKET
59
WASHER COMPRESSED AIR LINE TO BRACKET
62
NUT PUMP TO BRACKET
65
LOOM TIE LINE MOUNTING
65
LOOM TIE LINE MOUNTING 280 MM
68
CLAMPING PIECE IDLING ADJUSTMENT WIRE CABLE
69
CLAMP ,K 147121, Replaced By: N000000000319
69
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
69
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
71
SCREW CAB FLOOR COVERING M 6X25
71
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
74
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
74
WASHER COMPRESSED AIR LINE TO BRACKET
77
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
80
NUT PUMP TO BRACKET
