Поз.
Артикул
Описание
5
SUPPORT TRAILER PLUG SOCKET
11
SUPPORT BRAKE LINE COUPLINGS
23
BRACKET TRAILER PLUG SOCKET
26
BRACKET TRAILER PLUG SOCKET
32
BRACKET TRAILER PLUG SOCKET
38
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6555459340
45
BRACKET AT AIR RESERVOIR
55
CLAMP STEERING OIL TANK
60
SCREW BRACKET TO CROSS CONNECTION STRUT
60
SCREW , Replaced By: N304017008034
65
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
65
SCREW , Replaced By: A0099900101
65
SCREW , Replaced By: N000933008337
70
SCREW SUPPORT TO SUPPORT
75
NUT STRAP TO BRACKET
75
NUT , Replaced By: N910113010000
80
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
80
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
80
NUT , Replaced By: N913004008001
130
ADAPTER FITTING LINE CONNECTION TO ENGINE
135
NUT BRACKET TO SIDE MEMBER
135
ADAPTER FITTING LINE CONNECTION TO ENGINE
140
TEST CONNECTION
140
TEST CONNECTION BULKHEAD FITTING
145
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
150
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
155
SCREW. UNION SCREW LINE CONNECTION
160
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
165
NUT STRAP TO BRACKET
165
NUT , Replaced By: N910113010000
170
BRACKET COMPRESSED AIR LINES,K 168169
170
BRACKET , Replaced By: A3464310440
175
SCREW BRACKET TO SIDE MEMBER,K 168169
175
SCREW , Replaced By: A0089907401
180
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
180
NUT , Replaced By: N913004008001
185
LOOM TIE LINE MOUNTING 280 MM
