Поз.
Артикул
Описание
5
RADIATOR WITH SCREW FITTING
5
RADIATOR , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 752618, Replaced By: A6555002103
5
RADIATOR , Replaced By: A6555000403
6
SCREW WATER DRAIN
6
SCREW , Replaced By: A0005000085
6
SCREW WATER DRAIN
8
GASKET COOLING WATER DRAIN TO 656 500 00 03
8
SEAL RINGTO 000 553 03 05,000 553 18 05,
9
LOCK
10
SUPPORT RADIATOR,LEFT,K 096749
10
SUPPORT RADIATOR,LEFT,K 096750
11
SCREW CONSOLE TO SIDE MEMBER
14
NUT SUPPORT TO SIDE MEMBER
17
RUBBER MOUNTING RADIATOR
20
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
20
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
20
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
20
SCREW , Replaced By: N304017010028
21
SPRING WASHER STEERING COLUMN BRACKET TO CAB
23
WASHER RADIATOR TO RUBBER MOUNTING
23
WASHER , Replaced By: N000125010532
26
FAN SHROUD RADIATOR
29
DETENT FAN SHROUD TO RADIATOR
30
LOCK PULL TO FASTENER
30
LOCK , Replaced By: N912002008003
35
BOOT FAN SHROUD TO FAN RING
43
TANK COOLING WATER EXPANSION
44
RADIATOR CAP FILLER NECK
44
RADIATOR CAP , Replaced By: A0005016415
45
SEAL RING
47
RADIATOR CAP
50
RADIATOR CAP CENTRAL
50
RADIATOR CAP CENTRAL
53
GASKET O.D., 52 MM
56
GASKET O.D., 37 MM
59
DRAIN PIPE
62
SENDER UNIT COOLING WATER LEVEL INDICATOR
65
PLATE FROM EXPANSION TANK TO RADIATOR
65
PLATE FROM EXPANSION TANK TO RADIATOR 40X40 MM
68
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
68
BRACKET. LOCK , Replaced By: A6525040038
71
HOSE FROM EXPANSION TANK TO ENGINE
74
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
74
CLAMP , Replaced By: N916017011001
113
BRACKET , NOT USED
146
SCREW , Replaced By: N304017006016
146
SCREW PUMP TO BRACKET
149
NUT RETAINER LICENSE PLATE TO BRACKET
149
NUT RETAINER , Replaced By: A0019906791
149
NUT , Replaced By: A0009902291
152
SCREW DE-AERATION LINE TO RADIATOR
152
SCREW , Replaced By: A6739900032
155
CLAMP OIL-DIPSTICK GUIDE TUBE TO BRACKET
158
WASHER COMPRESSED AIR LINE TO BRACKET
158
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
161
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
161
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
161
NUT , Replaced By: N913004008001
