Поз.
Артикул
Описание
5
WIRE CABLE MANUAL CONTROL
5
WIRE CABLE MANUAL CONTROL
11
FITTED WASHER WIRE CABLE TO INSTRUMENT PANEL
14
NUT WIRE CABLE TO INSTRUMENT PANEL
17
KNOB IDLING ADJUSTMENT
23
CLAMPING PIECE IDLING ADJUSTMENT WIRE CABLE
24
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
24
CLAMP ,K 147121, Replaced By: N000000000319
26
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
26
SCREW , Replaced By: N000000001149
26
SCREW , Replaced By: A0029903712
29
WASHER COMPRESSED AIR LINE TO BRACKET
29
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
32
NUT PUMP TO BRACKET
32
NUT , Replaced By: N913004006001
41
BRACKET WIRE CABLE TO FRAME SIDE MEMBER
44
BRACKET WIRE CABLE TO FRAME SIDE MEMBER
44
BRACKET WIRE CABLE TO FRAME SIDE MEMBER
47
BRACKET WIRE CABLE TO FRAME SIDE MEMBER
54
BRACKET WIRE CABLE TO FRAME SIDE MEMBER
59
BRACKET WIRE CABLE TO FRAME SIDE MEMBER
63
SCREW LICENSE PLATE TO BRACKET
63
SCREW , Replaced By: N304017006020
63
SCREW PUMP TO BRACKET
65
WASHER COMPRESSED AIR LINE TO BRACKET
65
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
68
NUT PUMP TO BRACKET
68
NUT , Replaced By: N913004006001
71
CLAMPING PIECE IDLING ADJUSTMENT WIRE CABLE
72
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
72
CLAMP ,K 147121, Replaced By: N000000000319
77
SCREW CAB FLOOR COVERING M 6X25
80
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
80
SCREW , Replaced By: N000000001149
80
SCREW , Replaced By: A0029903712
83
WASHER COMPRESSED AIR LINE TO BRACKET
83
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
86
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
89
NUT PUMP TO BRACKET
89
NUT , Replaced By: N913004006001
92
LOOM TIE LINE MOUNTING 280 MM
92
LOOM TIE LINE MOUNTING
