Поз.
Артикул
Описание
56
SCREW FOLLOWER FLANGE TO PROPELLER SHAFT
56
SCREW FOLLOWER FLANGE TO PROPELLER SHAFT
56
SCREW , Replaced By: N308676016004
56
SCREW SUPPORT TO TRANSMISSION M 16X1.5X60
56
SCREW ENGINE MOUNTING TO SUPPORTING ARM
89
ROD LINK
92
BUSHING LINK TO BRACKET
95
WASHER EXHAUST MUFFLER TO STRAP
95
WASHER , Replaced By: N000125008443
98
COTTER PIN ROD TO LEVER
101
PULL ROD BRAKE POWER REGULATOR CONTROL 200 MM, TO BE ADAPTED DURING ASSEMBLY
104
CONNECTOR PULL ROD TO LEVER
107
CLAMP CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
110
CLAMP , Replaced By: N000000000665
110
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
110
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
113
LOCK RING PULL ROD TO LINK
116
LEVER ON ALB REGULATOR
119
WASHER , Replaced By: N000125008443
119
WASHER EXHAUST MUFFLER TO STRAP
122
COTTER PIN ROD TO LEVER
125
BRACKET ALB REGULATOR ON REAR AXLE
128
BRACKET SENSOR CABLE TO FRONT AXLE
131
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
131
NUT , Replaced By: N913004008001
134
BRACKET LINK TO CROSS MEMBER
137
SCREW PIPE CLAMP
137
SCREW , Replaced By: N304017008021
140
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
140
NUT , Replaced By: N913004008001
143
BRACKET BRACKET TO NUMMEK AXLE
146
BRACKET BRACKET TO NUMMEK AXLE
149
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
152
COVERING
155
COVERING INTERMEDIATE BEARING
158
WASHER
161
COTTER PIN CYLINDER TO BRACKET
164
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
167
REPAIR KIT BRAKE POWER REGULATOR WABCO
170
GUIDE SIGN LOAD-DEPENDING BRAKE,K 063802K 093236
170
GUIDE SIGN LOAD-DEPENDING BRAKE,K 063802K 093236
170
GUIDE SIGN LOAD-DEPENDING BRAKE,K 093236
170
GUIDE SIGN LOAD-DEPENDING BRAKE,K 093236
170
GUIDE SIGN LOAD-DEPENDING BRAKE
173
T-FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "21,22"
176
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
179
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
182
T-FITTING TRISTOP CYLINDER,CONNECTION: "11"
185
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
188
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
191
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
194
SCREW. UNION SCREW LINE CONNECTION
999
VALVE P.T.O.
999
TEST CONNECTION
999
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
999
BRAKE HOSE , Replaced By: A0004295135
999
LEVER BRAKE POWER REGULATOR CONTROL
999
BRACKET , Replaced By: A3914311240
999
METAL SPRING BELLOWS
999
METAL SPRING BELLOWS
999
BRACKET RELAY VALVE
