Поз.
Артикул
Описание
5
VALVE (TEST VALVE), 415 5 014668 416 5 000515 417 4 972023
10
NON-RETURN VALVE. VALVE WITH CHECK VALVE WABCO,5 433388
10
VALVE (CHECK VALVE)
15
VALVE SEAT RINGWABCO,5 433388
20
BUSHINGWABCO,5 433388
25
LOCK RINGWABCO,5 433388
27
ELBOW FITTING , Replaced By: A0049906471
27
ELBOW FITTING CHECK VALVE TO RELAY VALVE
29
T-FITTING CHECK VALVE TO RELAY VALVE
31
TANK RECESS. T-FITTING LINE CONNECTION
33
VALVE FRONT AXLE II RELAY VALVE "WABCO"
33
VALVE 3/2-WAY VALVE
35
REPAIR KIT RELAY VALVE TO 004 429 38 44,WABCO
35
REPAIR KIT RELAY VALVE BOSCH
38
FITTING RELAY VALVE,CONNECTION: "40"
40
BRACKET RELAY VALVE TO CROSS MEMBER
42
BRACKET RELAY VALVE TO SIDE MEMBER
45
VALVE (SHUTTLE VALVE)
50
VALVE. REPAIR KIT SHUTTLE VALVE
53
FITTING LINE CONNECTION
53
FITTING FRONT AXLE II RELAY VALVE,CONNECTION: "24"
53
FITTING AIR RESERVOIR,CONNECTION: "15",5 433280
55
TANK RECESS. T-FITTING LINE CONNECTION
55
TANK RECESS. T-FITTING LINE CONNECTION
60
FITTING LINE CONNECTION
65
TEST CONNECTION
65
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
65
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
65
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
65
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
70
VALVE (REDUCTION VALVE),5 359430
75
FITTING FRONT AXLE II RELAY VALVE,CONNECTION: "24"
80
BRACKET REDUCTION VALVE
85
VALVE LOAD/NO-LOAD, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
90
FITTING LOAD/NO-LOAD VALVE,CONNECTIONS: "10,21"
90
FITTING LOAD/NO-LOAD VALVE,CONNECTIONS: "10,21"
95
BRACKET LOAD/NO-LOAD VALVE
100
BRACKET LOAD/NO-LOAD VALVE
105
VALVE (3/2-WAY SOLENOID VALVE) "WABCO"
110
FITTING FROM 3/2-WAY VALVE TO PRESSURE CONTROL VALVE
115
FITTING BRAKE POWER REGULATOR W/RELAY VALVE, CONNECTION: "40"
