Поз.
Артикул
Описание
5
RESERVOIR EXPANSION TANK
8
LOCKING CAP
11
SEAL RING
14
STRAINER
17
CAP RESERVOIR DE-AERATION
20
MASTER CYLINDER CLUTCH
23
INTERMEDIATE PIECE
26
PLUG
29
CYLINDER. REPAIR KIT CLUTCH MASTER CYLINDER
32
SCREW COVER PLATE TO BRACKET
35
SPRING WASHER LICENSE PLATE TO BRACKET
38
ROD CLUTCH MASTER CYLINDER
41
NUT , Replaced By: N304035008001
41
NUT
44
ARTICULATION PIECE CLUTCH MASTER CYLINDER
44
ARTICULATION PIECE CLUTCH MASTER CYLINDER
47
NEEDLE BEARING JOINT TO PIN
47
NEEDLE BEARING JOINT TO PIN
47
NEEDLE BEARING JOINT TO PIN
47
NEEDLE BEARING JOINT TO PIN
50
WASHER BRACKET TO FENDER BRACKET
53
LOCK PLATE PUSH ROD TO CLUTCH PEDAL
56
PIN CLUTCH MASTER CYLINDER TO CLUTCH PEDAL
59
NUT , Replaced By: N913004008001
59
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
59
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
62
HOSE FROM RESERVOIR TO MASTER CYLINDER, ORDER BY THE METER
65
LINE CLUTCH LINE
65
LINE FROM MASTER CYLINDER TO PARTITION FITTING 1630 MM,K 130132
71
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
75
LINE FROM MASTER CYLINDER TO HOSE 95 MM,K 130133
77
UNION NUT LINE CONNECTION
77
UNION NUT
80
GLAND LINE CONNECTION
81
LINE FROM CLUTCH MASTER CYLINDER TO CLUTCH SLAVE CYLINDER 3550 MM,K 130133
81
LINE FROM CLUTCH MASTER CYLINDER TO CLUTCH SLAVE CYLINDER 4450 MM,K 130133
83
LOOM TIE LINE MOUNTING
84
FITTING (PARTS KIT),LINE RUPTURE
86
CLUTCH BOOSTER ,K 037846, Replaced By: A0002951418
86
CLUTCH BOOSTERWABCO,K 037847 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
86
CLUTCH BOOSTERKNORR, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
87
REPAIR KIT CLUTCH BOOSTER WABCO
87
REPAIR KIT CLUTCH BOOSTER KNORR
89
COVER PLATETO 000 295 02 18 , 000 295 09 18
92
BRACKETWABCO,K 037846
95
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
98
SCREW CLUTCH BOOSTER TO BELL HOUSING,K 037846
101
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
104
SEAL RING COMPRESSED AIR LINE TO CLUTCH BOOSTER WABCO
107
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
110
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
110
SEAL RING. SEALING RING , Replaced By: N007603016401
113
FITTING CLUTCH BOOSTER,CONNECTION: "4"
113
FITTING , Replaced By: A0029909768
116
BRACKET LINE TO FRONT PANEL
120
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
136
BRACKET BRACKET TO FAN SHROUD BRACKET
140
BRACKET BRACKET TO FAN SHROUD BRACKET,5 920754
143
ANGLE LINE MOUNTING
144
BRACKET HYDRAULIC LINE TO BELL HOUSING,5 547965K 130132
146
WASHER COMPRESSED AIR LINE TO BRACKET
146
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
148
BRACKET FUEL LINE TO BELL HOUSING
152
FITTING HYDRAULIC LINE TO BRACKET,K 130132
155
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
164
SCREW COVER PLATE TO BRACKET
164
SCREW , Replaced By: N304017006020
164
SCREW LICENSE PLATE TO BRACKET
167
NUT , Replaced By: N913004006001
167
NUT PUMP TO BRACKET
167
NUT PUMP TO BRACKET
170
CLAMP ,K 147121, Replaced By: N000000000319
170
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
170
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
176
SCREW , Replaced By: N304017006016
176
SCREW PUMP TO BRACKET
176
SCREW COVER PLATE TO BRACKET
185
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
188
NUT , Replaced By: N913004006001
188
NUT PUMP TO BRACKET
999
CLAMP LINE MOUNTING
