Поз.
Артикул
Описание
10
PITMAN ARM AT STEERING GEAR
10
PITMAN ARM AT STEERING GEAR
20
NUT PITMAN ARM TO STEERING BOX ASSEMBLY
30
DRAG LINK , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0004602705
30
DRAG LINK , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0004602605
30
DRAG LINK FROM PITMAN ARM TO FRONT AXLE I LEMFORDER,K 226467
30
DRAG LINKEHRENREICH
30
DRAG LINKLEMFOERDER
40
DRAG LINK END , Replaced By: A0014602248
40
DRAG LINK END R.H. THREAD EHRENREICH
40
DRAG LINK END , Replaced By: A0014607748
50
DRAG LINK FROM PITMAN ARM TO STEERING BRACKET I EHRENREICH, COMPONENT PARTS NOT AVAILABLE
50
DRAG LINK FROM PITMAN ARM TO STEERING BRACKET I LEMFOERDER, COMPONENT PARTS NOT AVAILABLE
50
ROD FROM PITMAN ARM TO INTERMEDIATE LEVER I, COMPONENT PARTS NOT AVAILABLE
50
DRAG LINK FROM PITMAN ARM TO INTERMEDIATE LEVER, COMPONENT PARTS NOT AVAILABLE
60
STEERING SUPPORTI
70
SCREW RIGHT FRONT RUBBER MOUNTING M16X1,5X50
70
SCREW GUSSET PLATE TO FRAME M 16X35
80
NUT TRAILER COUPLING TO REAR CROSS MEMBER M 16
90
STEERING INTERMEDIATE ARMI
90
STEERING INTERMEDIATE ARMI
100
GREASE NIPPLE
100
GREASE NIPPLE , Replaced By: N071412008102
110
SEAL RING INSIDE
120
THRUST WASHER INSIDE
130
NEEDLE BEARING INSIDE AND OUTSIDE
140
SPACER TUBE STEERING INTERMEDIATE ARM BEARING TO 622 461 00 40
150
THRUST WASHER OUTSIDE
160
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
160
NUT , Replaced By: N910113018004
170
CAP STEERING SUPPORT
180
DRAG LINK FROM STEERING BRACKET I TO STEERING BRACKET II, COMPONENT PARTS NOT AVAILABLE
180
DRAG LINK FROM STEERING BRACKET I TO STEERING BRACKET II, COMPONENT PARTS NOT AVAILABLE
190
STEERING SUPPORT INTERMEDIATE LEVER III
200
SCREW BRACKET TO SIDE MEMBER M 14X55,5 543914
200
SCREW BRACKET TO SIDE MEMBER,5 597425
200
HEXAGON HEAD BOLT. SCREW BRACKET TO CONSOLE
200
SCREW , Replaced By: N910105014010
200
SCREW REAR CROSS MEMBER,ANGLE,AND GUSSET PLATE TO SIDE MEMBERS
210
NUT PARTICLE FILTER M14
240
STEERING INTERMEDIATE ARM STEERING SUPPORT III
240
STEERING INTERMEDIATE ARM"II"
250
GREASE NIPPLE
250
GREASE NIPPLE , Replaced By: N071412008102
260
SEAL RING INSIDE TO 622 463 01 10
260
SEAL RING INSIDE
270
THRUST WASHER , Replaced By: A6574630162
270
THRUST WASHER INSIDE
280
NEEDLE BEARING INSIDE AND OUTSIDE
290
SEAL RING INSIDE AND OUTSIDE TO 622 463 01 10
300
SPACER TUBE INSIDE
310
THRUST WASHER , Replaced By: A6574630062
310
THRUST WASHER OUTSIDE
320
SEAL RING OUTSIDE TO 622 463 01 10
330
NUT TORSION BAR TO BEARING BRACKET,5 904661
330
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
330
NUT , Replaced By: N910113018004
340
CAP STEERING SUPPORT
