Поз.
Артикул
Описание
82
LINE VENT LINE, ORDER BY THE METER
82
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
86
FITTING (PARTS KIT),LINE RUPTURE
101
HOSE LEAK LINE, ORDER BY THE METER
104
SLEEVE LEAK LINE
218
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
226
PLASTIC PIPE RISING PIPE 4X6 MM
226
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
234
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
242
INSULATING HOSE FEED 11X0.7 MM, ORDER BY THE METER
250
HOSE LEAK LINE, ORDER BY THE METER
258
HOSE LEAK LINE
262
LINE , Replaced By: A3404701265, +001A3054760126, +001N916017011000
262
LINE FUEL COMPENSATING
266
LINE , Replaced By: A3404701265, +001A3054760126, +001N916017011000
266
LINE WITH BANJO UNION
269
HOSE LEAK LINE
272
CLAMP LEAK LINE TO CONNECTOR AT ENGINE
274
HOLLOW SCREW FUEL LINE TO FEED PUMP
274
HOLLOW SCREW , Replaced By: N915036010108
282
SEAL RING FUEL LINE TO FEED PUMP
290
SLEEVE FEED
290
SLEEVE LEAK LINE
298
CLIP LEAK LINE
306
BANJO UNION , Replaced By: N000000000363
314
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
314
CLAMP , Replaced By: N000000000665
322
BRACKET AT ENGINE,REAR
330
BRACKET FUEL LINES TO TRANSMISSION
330
BRACKET , Replaced By: A6205240340
338
BRACKET , Replaced By: A6454310740
338
BRACKET FUEL LINE TO BELL HOUSING
346
BRACKET FUEL LINE
350
PROTECTIVE PLATE TO MOUNT FUEL LINES
362
WASHER BRACKET TO LEFT SIDE MEMBER
366
SCREW , Replaced By: N007985005175
366
SCREW HOOK TO BRACKET
370
SCREW PROTECTION PLATE TO BRACKET
374
WASHER COMPRESSED AIR LINE TO BRACKET
374
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
378
NUT , Replaced By: N304032005005
378
NUT IN CASE OF SUBSEQUENT INSTALLATION
382
NUT BALL PIVOT TO LEVER
386
FITTING RETURN
394
NUT. UNION NUT RETURN
400
GROMMET FUEL LINE THRU FRAME SIDE MEMBER
406
LOOM TIE LINE MOUNTING 280 MM
406
LOOM TIE LINE MOUNTING
999
CONNECTOR , Replaced By: A0039908270
999
CONNECTOR BREATHER LINE CONNECTION
999
CLAMP FUEL LINE TO BRACKET
999
RUBBER PAD FUEL LINE TO BRACKET
999
CLAMP , Replaced By: A3129952420
999
CLAMP , Replaced By: A1109950401
