Поз.
Артикул
Описание
5
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
5
HOSE , Replaced By: A0009872827
10
FITTING , Replaced By: A0029906171
10
FITTING (PARTS KIT),LINE RUPTURE
15
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
20
FITTING (PARTS KIT),LINE RUPTURE
20
FITTING , Replaced By: A0029905971
25
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
30
ELBOW FITTING HOSE WIDTH, 6 MM,TO M22
30
ELBOW FITTING HOSE WIDTH, 9 MM,TO M22
30
ELBOW FITTING HOSE WIDTH, 8 MM, TO M 16
30
ELBOW FITTING , Replaced By: A0049905371
35
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
40
DISTRIBUTOR
45
CONNECTOR HOSE WIDTH, 9 MM,TO M22
45
CONNECTOR HOSE WIDTH, / I.D., 6 MM
45
CONNECTOR DISTRIBUTOR TO CAB
45
CONNECTOR HOSE WIDTH, 9 MM,TO M 22
47
SEAL RING
50
CONNECTOR , Replaced By: A0029905478
50
CONNECTOR DISTRIBUTOR TO CAB
50
CONNECTOR HOSE WIDTH, 6 MM,TO M16
50
CONNECTOR HOSE WIDTH, 6 MM, TO M22
52
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
52
T-FITTING , Replaced By: A0059903370
55
SCREW. UNION SCREW , Replaced By: A0009973734
55
SCREW. UNION SCREW LINE CONNECTION
60
SCREW. UNION SCREW LINE CONNECTION
65
SEAL RING , Replaced By: A0009940747
65
LOCK RING LINE CONNECTION
70
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
75
LOCK LINE CONNECTION
75
LOCK , Replaced By: A0009945448
80
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
85
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
85
REPAIR KIT , Replaced By: A0309971748
90
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
91
BRACKET COMPRESSED AIR LINES,K 168169
91
BRACKET , Replaced By: A3464310440
92
SCREW , Replaced By: A0089907401
92
SCREW BRACKET TO SIDE MEMBER,K 168169
93
GROMMET ,5 585846
94
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
94
NUT , Replaced By: N913004008001
95
LOOM TIE LINE MOUNTING 280 MM
95
LOOM TIE LINE MOUNTING
97
FITTING LINE CONNECTION
195
BRAKE LINE COUPLING SUPPLY, RED "WABCO"
195
BRAKE LINE COUPLING BRAKE,YELLOW "WABCO"
195
BRAKE LINE COUPLING BRAKE,YELLOW "GRAU"
195
BRAKE LINE COUPLING SUPPLY, RED "KNORR"
195
BRAKE LINE COUPLING BRAKE,YELLOW "BOSCH"
195
BRAKE LINE COUPLING , Replaced By: A0004299730
195
BRAKE LINE COUPLING , Replaced By: A0004299630
195
BRAKE LINE COUPLING BRAKE,YELLOW "KNORR"
195
BRAKE LINE COUPLING SUPPLY, RED "BOSCH"
195
BRAKE LINE COUPLING SUPPLY, RED "GRAU"
200
SEAL RING30X2 MM,BOSCH
205
SEAL RING25X2 MM,BOSCH
210
SEAL RING"GRAU"
215
SEAL RING33X2.5 MM,BOSCH
220
VALVE TAPPET22X4 MM,BOSCH
220
SEAL RING , Replaced By: A0049978240, +001A0004290483
220
SEAL RING22X4 MM,BOSCH
225
COVER BRAKE,YELLOW "WABCO"
225
COVER SUPPLY, RED "WABCO"
230
REPAIR KIT BRAKE LINE COUPLING "KNORR"
230
REPAIR KIT BRAKE LINE COUPLING "WABCO"
235
BRACKET , Replaced By: A3874292040
235
BRACKET AT FRAME
235
BRACKET BRAKE LINE COUPLING TO REAR CROSS MEMBER
240
BRACKET
240
BRACKET AT FRAME
240
BRACKET BRAKE LINE COUPLING,"BRAKE",K 119510 FROM IDENT NO.,SEE SPECIAL VERSION 46347, 46753, 46756
245
SCREW BRACKET TO CROSS CONNECTION STRUT
245
SCREW END PIECE TO EXHAUST PIPE M 10X25
245
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
245
SCREW , Replaced By: A0099900101
245
SCREW , Replaced By: N304017008034
245
SCREW , Replaced By: N000933008337
250
NUT , Replaced By: N910113010000
250
NUT , Replaced By: N913004008001
250
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
250
NUT STRAP TO BRACKET
255
FITTING LOAD/NO-LOAD VALVE,CONNECTION: "40",5 509133
260
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
265
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
285
BRACKET LINE TO SIDE MEMBER, NOT USED
290
SCREW JUNCTION BOX TO BRACKET
295
NUT , Replaced By: N913004008001
295
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004008001
999
SCREW CABLE HARNESS MOUNTING
999
SCREW , Replaced By: N304017008023
999
BRACKET CABLE HARNESS MOUNTING
999
BRACKET COMPRESSED AIR PIPING
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
