Поз.
Артикул
Описание
5
TANK OIL
5
TANK , Replaced By: A0004666202
8
OIL DIPSTICK , Replaced By: A0004660867
8
OIL DIPSTICK
11
FILLER CAP
11
FILLER CAP , Replaced By: A0004661268
14
SEAL RING
17
BRACKET
20
FILTER
20
FILTER
23
SCREW BRACKET TO CROSS MEMBER M 6X35
26
NUT , Replaced By: N913004006001
26
NUT PUMP TO BRACKET
29
BRACKET OIL TANK,5 593345
29
BRACKET OIL TANK,5 593345
32
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
32
SCREW CENTRAL LOCK TO CAB M 10X16
35
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
38
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
38
CLAMP , Replaced By: N000000000667
41
LINE FROM OIL TANK TO HOSE
41
LINE FROM OIL TANK TO HOSE
41
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
41
LINE FROM OIL TANK TO HOSE
44
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
44
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
44
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
44
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,5 701910
44
LINE FROM OIL TANK TO POWER STEERING PUMP AT ENGINE
44
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
47
NUT LINE CONNECTION
47
UNION NUT LINE CONNECTION, Replaced By: N000000006243
50
GLAND , Replaced By: A0019901267
50
SEAL CONE LINE CONNECTION
56
FITTING SUCTION LINE TO OIL PUMP
59
SCREW-IN FITTING DELIVERY LINE TO PUMP
59
FITTING DELIVERY LINE TO PUMP
65
LINE FROM PUMP TO HIGH PRESSURE HOSE
65
LINE FROM PUMP TO HIGH PRESSURE HOSE
65
LINE FROM PUMP TO HIGH PRESSURE HOSE
65
LINE FROM PUMP TO HIGH PRESSURE HOSE
65
LINE FROM PUMP TO HIGH PRESSURE HOSE, CIRCUIT I
68
UNION NUT LINE CONNECTION, Replaced By: N000000006239
68
UNION NUT LINE CONNECTION
71
GLAND , Replaced By: A0019901967
71
SEAL CONE LINE CONNECTION
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
77
LINE FROM HIGH PRESSURE HOSE TO STEERING
77
LINE FROM HIGH PRESSURE HOSE TO STEERING
77
LINE FROM HIGH PRESSURE HOSE TO STEERING
80
UNION NUT LINE CONNECTION
80
UNION NUT LINE CONNECTION, Replaced By: N000000006239
83
GLAND , Replaced By: A0019901967
83
SEAL CONE LINE CONNECTION
86
FITTING DELIVERY LINE TO PUMP
86
SCREW-IN FITTING DELIVERY LINE TO PUMP
89
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
92
LINE RETURN, FROM STEERING TO OIL TANK
92
LINE RETURN, FROM STEERING TO OIL TANK
92
LINE RETURN, FROM STEERING TO OIL TANK
92
LINE RETURN, FROM STEERING TO OIL TANK
95
UNION NUT LINE CONNECTION
98
GLAND LINE CONNECTION
101
HOSE DELIVERY LINE TO STEERING
104
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
104
CLAMP HOSE TO FITTING AND TO OIL TANK
110
BRACKET FUEL LINES TO TRANSMISSION
111
BRACKET COMPRESSED AIR LINES,K 168169
113
BRACKET DELIVERY AND SUCTION LINES TO FRAME
113
BRACKET DELIVERY AND SUCTION LINES TO FRAME
119
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
122
SCREW END PIECE TO EXHAUST PIPE M 10X25
125
SCREW BRACKET TO CROSS MEMBER M 12X1.5X40
125
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
125
SCREW , Replaced By: N308676012026
125
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
128
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
134
NUT STRAP TO BRACKET
134
NUT , Replaced By: N910113010000
140
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
140
CLAMP , Replaced By: A6739950001
140
CLAMP DELIVERY AND SUCTION LINES TO STEERING
140
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
140
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
143
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
143
CLAMP DELIVERY AND SUCTION LINES TO FRAME
143
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
146
SCREW , Replaced By: N000000001146
146
SCREW , Replaced By: N000000001422
146
HEXALOBULAR BOLT CLAMP ON BRACKET M6X30
146
SCREW CLAMP MOUNTING M 6X16
146
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
149
NUT PUMP TO BRACKET
149
NUT , Replaced By: N913004006001
999
THRUST RING SUCTION LINE TO OIL PUMP
999
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
999
TUBE FROM HIGH PRESSURE HOSE TO STEERING
999
SEALING CORD SUCTION LINE TO OIL PUMP
999
PROTECTIVE CAP
999
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
999
BRACKET OIL TANK
999
BRACKET OIL TANK
999
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
999
LINE FROM PUMP TO HIGH PRESSURE HOSE
999
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,K 097399K 209336
999
LINE , Replaced By: A0004291601, +001N915010020200
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE
999
ELBOW FITTING SUCTION LINE TO OIL PUMP
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
SEAL RING VALVE TO VALVE,K 025179
999
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
999
NUT SUCTION LINE TO OIL PUMP
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
BANJO UNION
999
HOLLOW SCREW SUCTION LINE TO OIL PUMP
