Поз.
Артикул
Описание
80
BRACKET COMPRESSED AIR LINE TO INTAKE MANIFOLD, LEFT FRONT
83
SCREW BRACKET TO ENGINE
86
WASHER
86
WASHER , Replaced By: N007349008007
89
FITTING FROM 3/2-WAY VALVE TO PRESSURE CONTROL VALVE
92
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
104
CLAMP LINE MOUNTING
110
CLAMP LINE MOUNTING
113
SCREW , Replaced By: N304017006016
113
SCREW PUMP TO BRACKET
116
NUT HYDRAULIC LINE TO BELL HOUSING
131
LOOM TIE BRAKE LINE MOUNTING
134
LOOM TIE LINE MOUNTING
134
LOOM TIE LINE MOUNTING 280 MM
140
VALVE (3/2-WAY SOLENOID VALVE) EKS
143
PROTECTIVE CAPWABCO
146
SEAL RINGWABCO
146
SEAL RINGBOSCH
148
SEAL RINGBOSCH
149
GASKET KITKNORR
152
SCREW VALVE TO BRACKET
152
SCREW VALVE TO BRACKET, Replaced By: N304014008002
155
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
155
NUT , Replaced By: N913004008001
155
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
161
BRACKET 3/2-WAY SOLENOID VALVE
161
BRACKET 3/2-WAY SOLENOID VALVE
164
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
164
SCREW , Replaced By: N304017008016
167
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
170
WASHER , Replaced By: N000125008443
170
WASHER EXHAUST MUFFLER TO STRAP
176
SCREW TO PLUG THE FREE CONNECTIONS
179
SEAL RINGBOSCH
182
HOLLOW SCREW HEATING CONNECTION
185
SEAL RING LINE CONNECTION
200
VALVE SHUTTLE VALVE, REPAIR IMPOSSIBLE
203
SCREW TWO-WAY VALVE TO BRACKET
206
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
206
WASHER , Replaced By: N009021005205
209
NUT TWO-WAY VALVE TO BRACKET
215
BRACKET TWO-WAY VALVE
215
BRACKET CONNECTOR TO FRAME
218
BRACKET CONNECTOR TO FRAME
218
BRACKET , Replaced By: A6504312840
221
SCREW , Replaced By: N000000001146
221
SCREW CLAMP MOUNTING M 6X16
222
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
222
SCREW , Replaced By: N304017008016
224
NUT , Replaced By: N913004006001
224
NUT PUMP TO BRACKET
230
HOLLOW SCREW FUEL LINE TO FEED PUMP
230
HOLLOW SCREW , Replaced By: N915036010108
233
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
236
SEAL RING FUEL LINE TO FEED PUMP
242
VALVE 3/2-WAY, EXHAUST BRAKE CONTROL BOSCH
242
VALVE 3/2-WAY, EXHAUST BRAKE CONTROL WABCO
245
REPAIR KIT 3/2-WAY VALVE WABCO
245
REPAIR KIT 3/2-WAY VALVE BOSCH
248
SPRING WASHER AT CAB FLOOR
251
NUT SUCTION LINE TO OIL PUMP
254
SCREW. UNION SCREW LINE CONNECTION
254
SCREW. UNION SCREW , Replaced By: A0009973734
257
BREATHER , Replaced By: A3933280065
257
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
260
SCREW PLUG , Replaced By: N000908012009
260
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
263
SEAL RING LINE CONNECTION
999
BRACKET BRACKET TO ENGINE,REAR
999
SHIM 3/2-WAY SOLENOID VALVE
