Поз.
Артикул
Описание
8
SWITCH,AUTOMATIC (TEMPERATURE SWITCH),D 373744
11
HYDRAULIC CLUTCH
14
SPACER RING , NOT USED
17
SENDER UNIT
20
SWITCH TRANSMISSION OIL TEMPERATURE CONTROL,D 273898D 373744
20
CABLE HARNESS
23
SWITCH (CONTROL UNIT),D 273898D 373744
23
SWITCH
26
CABLE HARNESS"1",D 273898D 373744
26
CABLE HARNESS
29
CABLE HARNESS
32
CABLE HARNESS
32
CABLE HARNESS
35
CABLE HARNESS
38
INDICATOR
41
CABLE HARNESS ,D 273898D 373744
41
CABLE HARNESS ,D 273898D 373744
41
PLUG SOCKET
41
PLUG SOCKET ,D 273898D 373744
41
CONNECTOR
44
SCREW , Replaced By: N304017010040
47
SPRING WASHER STEERING COLUMN BRACKET TO CAB
50
SCREW CROSS MEMBER TO SIDE MEMBERS
53
WASHER GROUND CABLE
56
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
59
NUT , Replaced By: N913004006001
62
SCREW BUZZER TO WINDOW LEVEL GIRDER
65
LOCK WASHER T-FITTING TO BRACKET
999
SCREW BEARING BRACKET TO SIDE MEMBER
999
CABLE HARNESS
999
SWITCH TRANSMISSION OIL TEMPERATURE CONTROL
999
CABLE HARNESS
999
SWITCH
999
ELECTRONICS (CONTROL UNIT)
999
999
LINE
999
OIL COOLER
999
999
HYDRAULIC CLUTCH
999
SWITCH PRESSURE SWITCH
