Поз.
Артикул
Описание
10
SIGN BOX REAR WINDOW PANE
10
SIGN BOX REAR WINDOW PANE
16
FLUORESCENT TUBE WHITE 36 W
16
FLUORESCENT TUBE WHITE 30 W
17
CRANK
17
CRANK
19
GLASS PANE
19
GLASS PANE
20
RIM
21
SOCKET FLOURESCENT TUBES 24V / 36W
21
SOCKET FLOURESCENT TUBES 24V / 36W
21
SOCKET FLOURESCENT TUBES 24V / 8W
24
SERIES REACTOR20 - 30V / 4 - 13W
24
SERIES REACTOR20 - 30V / 15 - 40W
80
BRACKET BOX TO BODY
80
BRACKET BOX TO BODY
86
SCREW COVERING TO BODY M 6 X 20,230416
86
SCREW COVERING TO BODY M 6 X 20,230416
86
SCREW BOX TO BODY
98
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
107
WASHER , Replaced By: N009021006208
107
WASHER BRACKET TO AIR INTAKE SCOOP
113
WASHER EXHAUST MUFFLER TO STRAP
119
COVERING SIGN BOX,230416
122
SCREW PUMP TO BRACKET
122
SCREW COVERING TO BODY M 6 X 20,230416
125
WASHER ALTERNATOR CONNECTION "B",774712
146
SIGN BOX REAR WINDOW PANE, UNTIL PRODUCTION BREAKPOINT DATE 02.05.01
146
SIGN BOX REAR WINDOW PANE, AS OF PRODUCTION BREAKPOINT DATE 03.05.01
152
INSERT TYPE SIGN
158
PIN
159
RETAINING ROPE169 MM, AS OF PRODUCTION BREAKPOINT DATE 03.05.01
159
RETAINING ROPE385 MM, AS OF PRODUCTION BREAKPOINT DATE 03.05.01
161
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
170
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
179
PAD INSERT TYPE SIGN,230416
182
RUBBER MOULDING , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
185
PLASTIC SECTION CABLE HARNESS TO ROOF RAIL
185
PLASTIC SECTION CABLE HARNESS TO ROOF RAIL
185
SEAL ,230417, FACELIFT ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
194
BRACKET SIGN BOX TO BODY,230417, FACELIFT
197
SCREW BRACKET TO BODY M 4 X 10,230417, FACELIFT
200
WASHER VALVE TO BRACKET,5 602406
