Mercedes N912004010102 - КОЛЬЦО ПРУЖИННОЕ

O 345 G,EURO 2 671.312

42 BRAKES - 250 PRESSURE REGULATOR,MUFFLER,DEHYDRATOR, FREEZING PROTECTION

Поз.
Артикул
Описание
95
A3068900143
98
A3068900343
101
A3068900092
104
A3068910087
107
A0009966640
110
N000000005765
HEXAGON NUT
110
N000439014203
NUT , Replaced By: N308675014001
110
N308675014001
NUT JOINT TO BRACKET
111
A0009870437
111
A0009870637
112
A0069970690
LOOM TIE. CLAMP BRAKE HOSE 45-55 MM, DISCONTINUED,PART IS NO LONGER REQUIRED
112
A0069972790
LOOM TIE LINE MOUNTING
112
N916026045000
CLAMP , Replaced By: A0069970690
112
N916026060000
CLAMP , Replaced By: A0069972790
113
A3578900001
116
A3068900401
122
N304017010028
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
125
N912004010102
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
128
A3578324914
128
A3578302214
128
A3578302314
128
A3578324714
131
N000125008443
WASHER EXHAUST MUFFLER TO STRAP
131
A4639901140
WASHER HINGE
131
N000125008417
WASHER TRAILER PLUG SOCKET TO BRACKET
134
N910113008003
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
134
N913023008003
NUT HORN TO BRACKET M8
137
A3578325014
140
N000923008021
143
N913023008003
NUT HORN TO BRACKET M8
143
N910113008003
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
146
N916016022206
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
149
N000933005097
SCREW BRACKET MOUNTING
152
N913001005003
