Поз.
Артикул
Описание
116
LEVER (INTERMEDIATE LEVER) BEHIND REAR AXLE,BOTTOM, TO BE ADAPTED DURING ASSEMBLY
122
PIN
128
BUSHING
134
SEAL RING
137
CYLINDRICAL PIN
140
GREASE NIPPLE FOR SPRING
149
SCREW BRACKET TO CAB REAR PANEL M 8X20
149
SCREWM 8X20
152
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
152
NUT HORN TO BRACKET M8
155
SPRING RELEASE SPRING
158
161
INSULATING HOSE HOSE LINE PROTECTION 13 MM, ORDER BY THE METER
164
BOOT
167
CLAMP LINE MOUNTING
167
CLAMP WIRE CABLE TO SIDE MEMBER AND TO TRANSMISSION
167
CLAMP DELIVERY AND SUCTION LINES TO FRAME
167
CLAMP PIPE ON FAN SHROUD
167
CLAMP COOLING WATER HOSES
167
CLAMP CLAMP ON TRANSVERSE SHAFT MOUNTING, LINKAGE
170
HEXAGON HEAD BOLT. SCREW CONSOLE TO COWL AND TO ROOF
170
SCREW , WITH DIESEL ENGINE
170
SCREW COMPRESSED AIR LINE TO ENGINE MOUNTING SUPPORTING ARM
173
WASHER6,4
176
LOCK WASHER CABLE TO FUSE BOX
179
NUT HEATING PIPE TO BRACKET
182
LOOM TIE365 MM
185
JOINT WIRE CABLE
188
HEXAGON HEAD BOLT. SCREW CONSOLE TO COWL AND TO ROOF
191
NUT HEATING PIPE TO BRACKET
194
NUT L.H. THREAD
197
TURNBUCKLE TURNBUCKLE
200
PULL ROD ACCELERATOR CONTROL
200
203
JOINT PULL ROD
206
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
206
BALL SOCKET AT CONTROL LEVER
209
NUT
212
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
215
NUT HEATING PIPE TO BRACKET
218
BUSHING MANUAL CONTROL CABLE
221
ROD LINK TO ACCELERATOR PEDAL
224
SNAP RING SPRING-LOADED PUSH ROD
227
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
227
SECURING CLIP. CIRCLIP ACCELERATOR CONTROL
230
BALL PIVOT ACCELERATOR PEDAL,4 859026
230
BALL PIVOT CONTROL LEVER TO INJECTION PUMP LEVER, Replaced By: N000000004467
233
SEAL RING MODULATION PRESSURE CONTROL
236
NUT
242
LOCK WASHER CABLE TO FUSE BOX
245
NUT
