Mercedes A0098203910 - ZB REGLER/TRANSISTOR

O 345 K,EURO 1 671.322

81 APPOINTMENTS - 310 SIGN BOX IL. 1

Поз.
Артикул
Описание
6
A6718100777
SIGN BOX WINDSHIELD
16
A0008203964
FLUORESCENT TUBE WHITE 36 W
16
A0008253695
FLUORESCENT TUBE WHITE 30 W
17
A0008170902
CRANK
17
A0008171002
CRANK
19
A0008170010
GLASS PANE
19
A0008170110
GLASS PANE
20
A0008220057
RIM
21
A0098203710
SOCKET FLOURESCENT TUBES 24V / 36W
21
A0098203810
SOCKET FLOURESCENT TUBES 24V / 36W
21
A0098203910
SOCKET FLOURESCENT TUBES 24V / 8W
35
A6718101777
SUPPORT SIGN BOX
155
A6718170379
INSERT TYPE SIGN
155
A6718170179
INSERT TYPE SIGN
158
HXB3739910107
PIN
161
N000094002059
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
176
A6718170097
PAD INSERT TYPE SIGN
182
HXB3739870157
RUBBER MOULDING , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
999
A0008100854
999
A0008130133
999
A0008130233
999
A0008160052
999
A0008205511
999
A0008205611
999
A0008205711
999
A0008205811
999
A0008208311
SHEET BARS
999
A0008208511
SHEET BARS
999
A0008251382
999
A0008251682
999
A0008260166
999
A0008260266
999
A6718270024
999
A6718210901
999
A6718210201
999
A6718210101
999
A6718207804
999
A6718207704
999
A6718200697
999
A0138100877
SIGN BOX LATERAL "LAWO" 16X112
999
A0128201504
999
A0128201404
999
A0009872462
999
A0009872362
