Поз.
Артикул
Описание
5
PLASTIC PIPE RISING PIPE 4X6 MM
5
PLASTIC PIPE RISING PIPE 4X6 MM
5
PLASTIC PIPE RISING PIPE 4X6 MM
5
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
8
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
11
UNION NUT
14
SEAL CONE
14
GLAND , Replaced By: A0019901667
17
SLEEVE LEAK LINE
20
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
20
CONNECTOR , Replaced By: A0029905378
23
FITTING , Replaced By: A0019909871
23
FITTING FROM PUMP TO CYLINDER
23
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
26
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
26
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
29
SEAL RING , Replaced By: A0009940747
29
LOCK RING LINE CONNECTION
29
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
32
LOCK LINE CONNECTION
32
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
32
LOCK , Replaced By: A0009945448
35
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
35
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
35
REPAIR KIT , Replaced By: A0309971748
38
BRACKET SENSOR CABLE TO FRONT AXLE
38
BRACKET , Replaced By: A3852670040
56
LOOM TIE LINE MOUNTING
59
DISTRIBUTOR ENGINE SHUT-OFF,5 766894
62
SCREW CONNECTOR
65
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
65
WASHER COMPRESSED AIR LINE TO BRACKET
68
NUT PUMP TO BRACKET
68
NUT , Replaced By: N913004006001
71
SCREW. UNION SCREW LINE CONNECTION
71
SCREW. UNION SCREW LINE CONNECTION
71
SCREW. UNION SCREW , Replaced By: A0009973734
77
PLUG DISTRIBUTOR,CONNECTIONS: "03,04,05",TO M 16,5 766894
80
VALVE EXHAUST BRAKE 3/2-WAY VALVE BOSCH
80
VALVE EXHAUST BRAKE 3/2-WAY VALVE WABCO
83
CUP 3/2-WAY VALVE WABCO
86
REPAIR KIT 3/2-WAY VALVE BOSCH
86
REPAIR KIT 3/2-WAY VALVE WABCO
89
NUT SUCTION LINE TO OIL PUMP
92
SPRING WASHER AT CAB FLOOR
95
PIPE SOCKET 3/2-WAY VALVE,CONNECTION: "30"
98
SCREW. UNION SCREW , Replaced By: A0009973734
98
SCREW. UNION SCREW LINE CONNECTION
999
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
SCREW , Replaced By: N304017006034
999
BRACKET DISTRIBUTOR TO CAB
999
CONNECTOR DISTRIBUTOR OUTPUT, COMPRESSED AIR LINE PLUG CONNECTION
999
CONNECTOR DISTRIBUTOR TO CAB
999
CONNECTOR DISTRIBUTOR TO CAB
999
SEAL RING
999
CONNECTOR HOSE WIDTH, 6 MM,TO M16
999
ELBOW FITTING
999
ELBOW FITTING HOSE WIDTH, 9 MM,TO M22
999
CONNECTOR , Replaced By: A0029905478
