Поз.
Артикул
Описание
5
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
5
PLASTIC PIPE RISING PIPE 4X6 MM
8
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
11
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
14
HOLLOW SCREW HEATING CONNECTION
17
SEAL RING LINE CONNECTION
20
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
20
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
23
LOCK , Replaced By: A0009945448
23
LOCK LINE CONNECTION
26
REPAIR KIT , Replaced By: A0309971748
26
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
29
BRACKET COMPRESSED AIR LINE, NOT USED
32
BRACKET COMPRESSED AIR LINE MOUNTING,5 181197
32
BRACKET , Replaced By: A6732601962
35
SHEET METAL SCREW FUEL STRAINER SCREEN TO FUEL TANK
35
SHEET METAL SCREW , Replaced By: N007981004339
35
SHEET METAL SCREW , Replaced By: N000000000459
38
VALVE DIFFERENTIAL LOCK CONTROL WABCO
38
VALVE DIFFERENTIAL LOCK CONTROL BOSCH
41
ACTUATING PARTWABCO
41
PROTECTIVE CAPBOSCH
44
SPRING INSIDE WABCO
47
SEAL RING INSIDE WABCO
50
SEAL RING
53
SEAL RING TOP WABCO
56
SEAL RING
59
UNIT IDENTIFICATION PLATE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3855841524
59
SYMBOL PLATE P.T.O. I
62
WASHER AT TWO-WAY VALVE
65
NUT 4/3-WAY VALVE TO SUBSTRUCTURE
68
SCREW. UNION SCREW , Replaced By: A0009973734
68
SCREW. UNION SCREW LINE CONNECTION
71
LOOM TIE LINE MOUNTING
74
HYDRAULIC PUMP SERVICE WITH DUMPING PLATFORM TYPE 324/31
74
HYDRAULIC PUMP SERVICE WITH DUMPING PLATFORM,5 715692
74
HYDRAULIC PUMP SERVICE WITH DUMPING PLATFORM TYPE 234/2
77
VALVE
80
PISTON
83
SEAL RING
86
SPRING , ONLY USED ON DUMP TRUCK ASSEMBLIES
89
VALVE CHECK VALVE
92
BALL10 MM
95
SPRING CHECK VALVE, ONLY USED ON DUMP TRUCK ASSEMBLIES
98
SCREW PLUG
101
SEAL RING LINE CONNECTION
104
SEAL RING
107
GASKET CASE PART I TO CASE PART II
110
GASKET CONNECTION FLANGE
