Поз.
Артикул
Описание
5
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE BOSCH
5
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE KNORR
5
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE KNORR
5
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE KNORR
8
REPAIR KIT BRAKE POWER REGULATOR WABCO
8
REPAIR KIT BRAKE POWER REGULATOR BOSCH
8
REPAIR KIT COVERING BOSCH
8
REPAIR KIT VALVE BOSCH
8
REPAIR KIT , Replaced By: A0004300207
11
GUIDE SIGN LOAD-DEPENDING BRAKE, FROM IDENT NO. 5 000001 - 5 799999 5 800000 - 5 812730 5 900000 - 5 936365
11
GUIDE SIGN ON GLOVE COMPARTMENT REAR PANEL
11
GUIDE SIGN ON GLOVE COMPARTMENT REAR PANEL
11
GUIDE SIGN LOAD-DEPENDING BRAKE,5 3976465 917042
11
GUIDE SIGN LOAD-DEPENDING BRAKE
14
WASHER , Replaced By: N000125008443
14
WASHER EXHAUST MUFFLER TO STRAP
17
NUT , Replaced By: N913004008001
20
BRACKET BRAKE BOOSTER ASSEMBLIES
20
BRACKET BRAKE POWER REGULATOR
23
SCREW HOLLOW RUBBER SPRING TO CAB,5 956657
23
SCREW BRACKET TO FRAME
23
SCREW , Replaced By: N308676012011
23
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
29
NUT , Replaced By: N910113010000
29
NUT STRAP TO BRACKET
29
NUT END PIECE TO EXHAUST PIPE
29
NUT SUPPORT TO SIDE MEMBER
32
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
35
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
35
SCREW PLUG , Replaced By: N000908022011
35
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
38
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
41
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
50
LEVER BRAKE POWER REGULATOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
53
PULL ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT, TO BE ADAPTED DURING ASSEMBLY
56
CONNECTOR PULL ROD TO LEVER
59
CLAMP , Replaced By: N000000000665
59
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
62
CLAMP CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
65
BALL SOCKET , Replaced By: A3579910622
65
BALL SOCKET BRAKE POWER REGULATOR CONTROL,5 574483
65
BALL SOCKET PULL ROD
71
WASHER , Replaced By: N000125008443
71
WASHER EXHAUST MUFFLER TO STRAP
74
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
77
NUT
95
BRACKET OPERATING ROD, TO BE ADAPTED DURING ASSEMBLY
95
BRACKET OPERATING ROD, TO BE ADAPTED DURING ASSEMBLY
96
BALL PIVOT
98
SCREW BRACKET TO REAR AXLE HOUSING
101
SPACER RING BRACKET TO REAR AXLE HOUSING
999
SEAL RING AIR RESERVOIR,CONNECTIONS: "24,34"
999
ADHESIVE FOIL GUIDE SIGN
999
SCREW. UNION SCREW LINE CONNECTION
999
SCREW. UNION SCREW LINE CONNECTION
999
REPAIR KIT BRAKE POWER REGULATOR KNORR
999
REPAIR KIT BRAKE POWER REGULATOR TO 002 431 05 12,KNORR
