Поз.
Артикул
Описание
5
BRAKE VALVE (SERVICE BRAKE VALVE) KNORR
5
BRAKE VALVE (SERVICE BRAKE VALVE) BOSCH
5
BRAKE VALVE (SERVICE BRAKE VALVE) WABCO
8
REPAIR KITWABCO
8
REPAIR KIT SERVICE BRAKE VALVE BOSCH
8
REPAIR KIT SERVICE BRAKE VALVE BOSCH, Replaced By: A0004303506
11
NUT , Replaced By: N913004008001
11
NUT , Replaced By: N913004008004
17
SCREW. UNION SCREW LINE CONNECTION
20
SCREW. UNION SCREW LINE CONNECTION
20
SCREW. UNION SCREW , Replaced By: A0009973734
23
DISTRIBUTOR LESS CHECK VALVE
26
BRACKET DISTRIBUTOR
29
GUIDE BUSHING TWO-WAY VALVE TO FRAME
32
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
32
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
32
SCREW , Replaced By: N304017008028
32
SCREW DISTRIBUTOR TO FRAME SIDE MEMBER
35
NUT , Replaced By: N913004008001
38
SCREW. UNION SCREW LINE CONNECTION
41
VALVE (RELAY VALVE) BOSCH, REPAIR IMPOSSIBLE
41
VALVE (RELAY VALVE) WABCO, REPAIR IMPOSSIBLE
41
VALVE (RELAY VALVE) GRAU
41
VALVE (RELAY VALVE) KNORR
41
VALVE (RELAY VALVE) BOSCH
41
VALVE (RELAY VALVE) BOSCH
41
VALVE (RELAY VALVE) WABCO
44
VALVE SEATGRAU
47
GASKET34X2X6 MM,GRAU
50
SEAL RING22.3X2.4 MM,GRAU
53
SEAL RING28X2 MM,GRAU
56
SEAL RINGTO 000 429 28 95,GRAU
59
SEAL RING86X2 MM,GRAU
62
REPAIR KITKNORR
62
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
62
REPAIR KIT , Replaced By: A0004301109
62
REPAIR KITWABCO
65
VALVEBOSCH
65
VALVE GASKET KIT TO 003 429 16 44,BOSCH,UP TO 03.82
65
REPAIR KIT , Replaced By: A0004201071
71
WASHER EXHAUST MUFFLER TO STRAP
71
WASHER , Replaced By: N000125008443
74
NUT , Replaced By: N913004008001
77
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
77
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
80
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
83
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
86
THRUST RING CHECK VALVE TO AIR RESERVOIR
89
O-RING CHECK VALVE TO AIR RESERVOIR
95
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
BRACKET DISTRIBUTOR
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
999
SCREW , Replaced By: N304017008040
999
SCREW BRACKET TO SIDE MEMBER
999
SEAL RING AIR RESERVOIR,CONNECTIONS: "24,34"
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
999
NUT STRAP TO BRACKET
999
HEXALOBULAR BOLT. SCREW MANUAL PUMP BRACKET TO FENDER BRACKET
999
NUT , Replaced By: N910113010000
