Поз.
Артикул
Описание
5
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
5
PLASTIC PIPE AERATION, ORDER BY THE METER
8
FITTING , Replaced By: A0029905971
8
FITTING (PARTS KIT),LINE RUPTURE
11
ELBOW FITTING , Replaced By: A0049905371
11
ELBOW FITTING HOSE WIDTH, 6 MM,TO M22
14
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
14
PLASTIC PIPE RISING PIPE 4X6 MM
14
PLASTIC PIPE RISING PIPE 4X6 MM
17
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
20
UNION NUT
23
GLAND , Replaced By: A0019901667
26
SLEEVE LEAK LINE
32
CONNECTOR , Replaced By: A0029905378
32
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
35
FITTING , Replaced By: A0019909871
35
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
35
FITTING FROM PUMP TO CYLINDER
36
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
38
SEAL RING , Replaced By: A0009940747
38
LOCK RING LINE CONNECTION
41
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
44
LOCK , Replaced By: A0009945448
44
LOCK LINE CONNECTION
47
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
50
REPAIR KIT , Replaced By: A0309971748
50
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
53
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
56
BRACKET , Replaced By: A3852670040
56
BRACKET SENSOR CABLE TO FRONT AXLE
59
LOOM TIE LINE MOUNTING
62
DISTRIBUTOR HOSE WIDTH, 6 MM
65
DISTRIBUTOR
68
SCREW CONNECTOR
71
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
74
NUT , Replaced By: N913004006001
74
NUT PUMP TO BRACKET
77
SCREW. UNION SCREW LINE CONNECTION
80
SCREW. UNION SCREW , Replaced By: A0009973734
80
SCREW. UNION SCREW LINE CONNECTION
80
SCREW. UNION SCREW LINE CONNECTION
83
PLUG DISTRIBUTOR,CONNECTIONS: "03,04,05",TO M 16,5 766894
83
PLUG DISTRIBUTOR,CONNECTIONS: "03,04,05",TO M 16,5 766894
86
VALVE EXHAUST BRAKE 3/2-WAY VALVE BOSCH
86
VALVE EXHAUST BRAKE 3/2-WAY VALVE WABCO
89
CUP 3/2-WAY VALVE WABCO
92
REPAIR KIT 3/2-WAY VALVE WABCO
92
REPAIR KIT 3/2-WAY VALVE BOSCH
95
NUT SUCTION LINE TO OIL PUMP
98
SPRING WASHER AT CAB FLOOR
101
PIPE SOCKET 3/2-WAY VALVE,CONNECTION: "30"
104
FITTING 3/2-WAY VALVE,CONNECTION: "20",5 7668945 800000-5 806949
107
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
110
SCREW. UNION SCREW , Replaced By: A0009973734
110
SCREW. UNION SCREW LINE CONNECTION
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
SCREW , Replaced By: N304017006034
999
BRACKET DISTRIBUTOR TO CAB
999
CONNECTOR DISTRIBUTOR OUTPUT, COMPRESSED AIR LINE PLUG CONNECTION
999
CONNECTOR DISTRIBUTOR TO CAB
999
CONNECTOR DISTRIBUTOR TO CAB
999
CONNECTOR DISTRIBUTOR TO CAB
999
SEAL RING
