Поз.
Артикул
Описание
5
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
8
FITTING (PARTS KIT),LINE RUPTURE
8
FITTING , Replaced By: A0029905971
11
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
14
PLASTIC PIPE RISING PIPE 4X6 MM
14
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
17
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
20
HOSE RETURN LINE 8/13 MM,K 169122
20
HOSE BREATHER LINE TO SENDER UNIT, Replaced By: A6734760126
23
BANJO UNION FEED LINE
26
FITTING RETURN LINE
29
UNION NUT
32
INTERMEDIATE PIECE FEED LINE AND RETURN LINE,K 169122
35
SLEEVE LINE CONNECTION
35
SLEEVE LEAK LINE
38
LOOM TIE , Replaced By: N916002012100
38
CLAMP LINE CONNECTION
41
HOSE HAND BRAKE VALVE BLEEDING 100 MM, ORDER BY THE METER
44
HOSE LEAK LINE, ORDER BY THE METER
47
LOOM TIE VENT VALVE TO FUEL TANK
50
CLAMP , Replaced By: N916033011100
50
CLAMP CHECK VALVE,K 169122
50
CLAMP BREATHER LINE, FOR USE WITH SHORT MERCEDES-BENZ CAB5 3506525 495522
53
CLIP CABLE HARNESS TO ROOF RAIL
53
CLIP , Replaced By: A0009881878
56
CLAMP , Replaced By: N916033011100
56
CLAMP CHECK VALVE,K 169122
59
HOSE LEAK LINE
62
CLIP LEAK LINE
65
CLAMP LINE MOUNTING
65
CLAMP BREATHER LINE, FOR USE WITH SHORT MERCEDES-BENZ CAB5 3506525 495522
65
CLAMP LINE CONNECTION
68
CLAMP LEAK LINE TO CONNECTOR AT ENGINE
71
GROMMET FOR PASSAGE OF LINE
71
GROMMET BATTERY CABLE THRU SIDE MEMBER
74
LOOM TIE LINE MOUNTING 280 MM
74
LOOM TIE LINE MOUNTING
77
HOLLOW SCREW FUEL LINE TO FEED PUMP
77
HOLLOW SCREW , Replaced By: N915036010108
80
SEAL RINGTO 000 553 03 05,000 553 18 05,
999
PLASTIC PIPE FUEL LINE 16X2 MM, ORDER BY THE METER
999
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
999
PLASTIC PIPE AERATION, ORDER BY THE METER
